M VESA Deskmount HD Dual Vertical Widescreen
Introduction
M VESA Deskmount HD Dual Vertical Widescreen 32" - 50" frees up space and allows positioning of your display for greater productivity. Flexible, sleek and streamlined, the Dual Vertical version you can position two screens ontop of each other. Create a monitorwall on your desk.
Reposition your LCD´s with ease and align them with the ones positioned next to each other. Tilt, upwards tilt, left or right is now just a matter of your choice.
Finally comfort and ergonomics is really possible to achieve while building a multiple screen solution on a desk. With the M VESA Deskmount HD Dual Vertical Widescreen 32" - 50" you can easily manage each screens specific position.
M VESA Deskmount HD Dual Vertical Widescreen 32" - 50" works with almost all LCD screens on the market supporting VESA standards of 75/100mm holding screens weight up to 24 kg each, height of pillar is 800 mm allowing two screens.
Specifications
| Mounting | |
|---|---|
| Maximum weight capacity (per display) | 24 kg |
| Desk thickness (min) | 1 cm |
| Desk thickness (max) | 6 cm |
| Minimum screen size | 81.3 cm (32") |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Number of displays supported | 2 |
| Mounting type | Desk |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Mounting | Clamp/Bolt-through |
| Maximum weight capacity | 48 kg |
| Maximum screen size | 127 cm (50") |
| Ergonomics | |
| Height adjustment | Yes |
| Swivel angle range | -20 - 20° |
| Tilt angle range | -15 - 20° |
| Angle of rotation | 360° |
| Height adjustment type | Manual |
| Tilt adjustment | Yes |
| Technical details | |
| Mounting type | Desk |
| Product colour | Black |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Weight & dimensions | |
| Package width | 210 mm |
| Package depth | 850 mm |
| Package height | 200 mm |
| Width | 170 mm |
| Depth | 190 mm |
| Height | 800 mm |
| Weight | 8 kg |
| Package weight | 9.5 kg |
| Packaging data | |
| Package weight | 9.5 kg |
| Other features | |
| Mounting type | Desk |
| Mounting | Clamp/Bolt-through |
