HDMI TO DISPLAYPORT ADAPTER 4K
Introduction
4K 60Hz | HDR | HDCP 2.2 | Ultrawide Display Support
This HDMI® to DisplayPort adapter connects a 4K 60Hz HDMI video source, such as a laptop or desktop, to a DisplayPort monitor or projector.
4K 60Hz Resolution
This 1ft (30cm) HDMI to DisplayPort adapter supports up to 3840x2160 60Hz with HDR, HDCP 2.2, and 2-channel DisplayPort audio. In addition, it supports 4K 30hz, 1080p, and ultrawide resolutions up to 3440x1440 60Hz.
Extended Cables
The HDMI to DP converter features a 1ft (30cm) cable between the HDMI and DP connectors, reducing strain on ports and connectors. The adapter includes an attached 1ft (30cm) USB-A cable for connecting to a nearby powered USB port or a USB wall charger.
Comprehensive Compatibility
Plug and play setup is compatible with any HDMI enabled laptop, desktop, Ultrabook, MacBook, or Chromebook. The HDMI to DP Adapter utilizes the video capabilities of the host device, reducing CPU usage that may occur with driver-based video adapters. Works with any operating system, including Windows, macOS, Ubuntu, and ChromeOS.
This product is backed for 3-years by StarTech.com, including free 24/5 multi-lingual technical assistance .
Specifications
| Features | |
|---|---|
| Chipset | LT6711A |
| HDMI version | 2.0 |
| DisplayPort version | 1.2 |
| Product colour | Black, Grey |
| Cable length | 0.3 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| Maximum resolution | 3840 x 2160 pixels |
| HDCP | Yes |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.2 |
| High Dynamic Range (HDR) supported | Yes |
| Power source | USB |
| Voltage rating | 5 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Sustainability | |
| Sustainability compliance | Yes |
| Technical details | |
| Sustainability compliance | Yes |
| Compliance certificates | CE, RoHS |
| Other features | |
| Width | 365 mm |
| Height | 11 mm |
| Depth | 20 mm |
| Weight & dimensions | |
| Width | 365 mm |
| Height | 11 mm |
| Depth | 20 mm |
| Weight | 38 g |
| Package width | 126 mm |
| Package depth | 199 mm |
| Package height | 21 mm |
| Package weight | 43 g |
| Packaging data | |
| Package width | 126 mm |
| Package depth | 199 mm |
| Package height | 21 mm |
| Package weight | 43 g |
| Logistics data | |
| Master (outer) case width | 509 mm |
| Master (outer) case length | 335 mm |
| Master (outer) case height | 219 mm |
| Products per master (outer) case | 180 pc(s) |
