1M 8K60HZ HDMI CABLE BLACK LINE
Introduction
From the lines cable connectivity concept developed by Lindy, Black Line High Speed HDMI cables are fully featured, entry level high resolution connection solutions, perfect for home and small office use.
Black Line 8k60hz or 4K120hz cables feature triple shielded construction with 30AWG copper coated steel conductors for premium performance and corrosion resistance. Nickel connectors and gold flashed contacts maintain signal integrity and reliability.
UHD resolutions up to 7680x4320@60Hz and 3840x2160@120hz are supported. 8K Black Line HDMI cables are also capable of transmitting 32 channel audio and Dolby® Atmos and DTS:X
The 8K Black line HDMI cable supports 48Gbps bandwidth capacity in cable lengths up to 5m.
Specifications
| Features | |
|---|---|
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum refresh rate | 120 Hz |
| Product colour | Black |
| Cable length | 1 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Copper |
| AWG wire size | 30 |
| HDMI version | 2.1 |
| Data transfer rate | 48 Gbit/s |
| Supported graphics resolutions | 7680 x 4320 |
| Cable jacket material | Nylon/Polyvinyl Chloride (PVC) |
| RGB support | 4:4:4 |
| Colour sampling | 4:4:4 |
| Contact material | Phosphor copper |
| Connector material | Aluminium |
| Cable type | Round cable |
| Shield material | Aluminium |
| Certification | RoHS & REACH UL |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 80 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Certificates | |
| Certification | RoHS & REACH UL |
| Weight & dimensions | |
| Connector 1 dimensions (WxDxH) | 20 x 34.2 x 10.9 mm |
| Connector 2 dimensions (WxDxH) | 20 x 34.2 x 10.9 mm |
| Package type | Polybag |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Package type | Polybag |
| Packaging data | |
| Package type | Polybag |
| Quantity per pack | 1 pc(s) |
