STARTECH.COM CDP2DP146B STARTECH.COM 6FT USB C TO DISPLAYPORT 1.4

*Image accuracy is not guaranteed
Please do not rely on the image for your purchase.

** All heavy items above 25KG will be charged shipping cost as per actual.
Please contact us for a shipping quote before placing order.

6FT USB C TO DISPLAYPORT 1.4

Introduction

USB-C™ Video Adapter Cable | Thunderbolt™ 3 Compatible | HBR3

This USB-C to DisplayPort 1.4 cable lets you connect your USB Type-C device to a DisplayPort monitor with just one cable, providing you with a convenient, clutter-free solution.

Incredible Picture Quality

Supporting four times the resolution of 4K, this 8K DP 1.4 adapter cable delivers the stunning quality of UHD at resolutions up to 7680×4320; and also features HBR3 functionality, providing a bandwidth of up to 32.4Gbps.

With cutting-edge picture quality, this cable is ideal for:

• Displaying crisp digital signage walls
• Creating eye-catching visuals for photography and videography

The USB-C to DP cable is backward compatible with 4K and 1080p displays, which makes it a great accessory for home, office or other work environments, while future-proofing for 8K implementation.

At 6 ft. (1.8 m) in length, this DisplayPort adapter cable delivers a direct connection that eliminates excess cabling, ensuring a tidy installation. For installations requiring a shorter length, we also offer a 3.3 ft. (1 m) DisplayPort cable, enabling you to customize your connection needs. Clutter-Free Installation

Hassle-Free Setup

To ensure easy operation, this DisplayPort converter cable supports plug-and-play installation, removing the need for additional software or drivers.

CDP2DP146B is backed by a 3-year StarTech.com warranty and free lifetime technical support.

Note:

• Your USB-C device must support DP Alt Mode to work with this adapter cable.
• To achieve 8K resolutions, your source and your destination must support DisplayPort 1.4.

Specifications

Features
ChipsetSTM32F072CBY6TR
DisplayPort version1.4
Product colourBlack
Cable length1.8 m
Connector 1USB Type-C
Connector 2DisplayPort
Connector 1 genderMale
Connector 2 genderMale
Maximum resolution7680 x 4320 pixels
Supported graphics resolutions1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3860 x 2160, 4096 x 2160, 7680 x 4320
CertificationCE, FCC, REACH
Connector 1 form factorStraight
Connector 2 form factorStraight
Maximum refresh rate60 Hz
Supported audio channels7.1
Operational conditions
Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)80 - 90%
Certificates
CertificationCE, FCC, REACH
Compliance certificatesRoHS
Other features
Width200 mm
Height11 mm
Depth1800 mm
Weight & dimensions
Width200 mm
Height11 mm
Depth1800 mm
Weight57 g
Package width157 mm
Package depth181 mm
Package height27 mm
Package weight100 g
Packaging data
Package width157 mm
Package depth181 mm
Package height27 mm
Package weight100 g
Quantity per pack1 pc(s)
Packaging content
Quantity per pack1 pc(s)
Technical details
Harmonized System (HS) code84733080
Compliance certificatesRoHS
Logistics data
Master (outer) case width507 mm
Master (outer) case length343 mm
Master (outer) case height232 mm
Products per master (outer) case60 pc(s)
Harmonized System (HS) code84733080
