2M DISPLAYPORT CABLE 10 PACK DP
Introduction
Set up multiple 4K UHD connections using this DisplayPort Cable 10 Pack
Faciliate multi-monitor setups using this DisplayPort 1.2 Cable 10-Pack. This cable facilitates high bandwidth video and multi-channel audio and is ideal for 4K workstations, docks, and high performance GPUs. Connect a 4K 60Hz UHD DisplayPort monitor to a host computer or MST hub.
Seamless Compatibility
For seamless operation between DisplayPort-enabled devices, the DisplayPort 1.2 Cable is VESA Certified for guaranteed DP 1.2 and backward compatibility with DP 1.1.
Durable Design
This DisplayPort cable features a flexible TPE outer jacket and can be routed around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching gold-plated DP connectors attach securely to prevent accidental disconnection.
Supported DisplayPort 1.2 Features:
The Certified DisplayPort Cable supports the following DP 1.2 features:
• Resolutions up to 4K 60Hz, using a compatible DP source and display
• Supports high refresh rates including 1080p 120Hz and 1440p 75Hz
• High-Bandwidth Digital Content Protection (HDCP) for a secure connection between source and display
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• 8 Uncompressed Digital Audio Channels
• Backward compatible with DP 1.1
This DP 1.2 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.
Specifications
| Features | |
|---|---|
| Cable shielding | Aluminum mylar foil |
| Latching connectors | Yes |
| Cable rating | CMG (CM) |
| Number of conductors | 19 |
| Product colour | Black |
| Cable length | 2 m |
| Connector 1 | DisplayPort |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Nickel |
| Jacket material | Thermoplastic elastomer (TPE) |
| AWG wire size | 28 |
| Data transfer rate | 21.6 Gbit/s |
| Maximum resolution | 3840 x 2160 pixels |
| HDCP | Yes |
| Maximum refresh rate | 120 Hz |
| Multi-Stream Transport (MST) | Yes |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Cable type | Round cable |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Weight & dimensions | |
| Cable diameter | 7.3 mm |
| Weight | 134 g |
| Package weight | 1.4 kg |
| Package width | 350 mm |
| Package depth | 460 mm |
| Package height | 100 mm |
| Packaging data | |
| Cable diameter | 7.3 mm |
| Package weight | 1.4 kg |
| Weight | 134 g |
| Package width | 350 mm |
| Package depth | 460 mm |
| Package height | 100 mm |
| Quantity per pack | 10 pc(s) |
| Packaging content | |
| Quantity per pack | 10 pc(s) |
| Technical details | |
| Compliance certificates | CE, RoHS |
| Logistics data | |
| Products per master (outer) case | 5 pc(s) |
| Master (outer) case width | 320 mm |
| Master (outer) case length | 500 mm |
| Master (outer) case height | 210 mm |
