3FT DISPLAYPORT TO DVI CABLE DP
Introduction
Eliminate clutter by connecting your PC directly to the monitor using this short adapter cable
This 3-foot DisplayPort™ to DVI-D adapter cable lets you connect your DisplayPort (DP) equipped Ultrabook™, laptop or desktop computer to a DVI monitor or projector with no additional adapters or cables required. The passive adapter supports video resolutions up to 1920x1200 (WUXGA), perfect for high-resolution applications.
Hassle-free setup
For the simplest and most discreet installation, this DP to DVI-D adapter connects directly from your DisplayPort video source to the DVI port on your display. It doesn't need a power source, unlike some converter dongles that require active power and separate bulky video cabling.
Continue using your existing DVI display
With this DP to DVI cable, you can bridge the gap between old and new technologies by converting your existing DVI display to work with your DP video source.
Upgrading every component in your A/V setup can be costly and time consuming. This cost-effective adapter lets you save the expense and hassle of buying a new display, by ensuring your existing DVI display will work with your DisplayPort equipment.
Clutter-free installation
This 3 ft. adapter cable delivers a compact connection that eliminates excess to ensure a tidy, professional installation. For longer installations, we also offer a 6 ft DP to DVI cable (DP2DVIMM6), enabling you to choose the right cable length for your custom installation needs.
The DP2DVI2MM3 is backed by a 3-year StarTech.com warranty and free lifetime technical support.
Specifications
| Features | |
|---|---|
| Converter type | Passive |
| DisplayPort version | 1.2 |
| Product colour | Black |
| Cable length | 0.914 m |
| Connector 1 | DisplayPort |
| Connector 2 | DVI-D |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Jacket material | Polyvinyl chloride (PVC) |
| Maximum resolution | 1920 x 1200 pixels |
| Supported video modes | 1080p |
| Plug and Play | Yes |
| Certification | FCC, CE, REACH |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Dual Link DVI | No |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 0 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Certificates | |
| Certification | FCC, CE, REACH |
| Compliance certificates | RoHS |
| Other features | |
| Depth | 914 mm |
| Weight & dimensions | |
| Depth | 914 mm |
| Weight | 24.4 g |
| Package width | 198 mm |
| Package depth | 128 mm |
| Package height | 21 mm |
| Package weight | 60 g |
| Packaging data | |
| Package width | 198 mm |
| Package depth | 128 mm |
| Package height | 21 mm |
| Package weight | 60 g |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Harmonized System (HS) code | 84733080 |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 429 mm |
| Master (outer) case length | 466 mm |
| Master (outer) case height | 430 mm |
| Products per master (outer) case | 220 pc(s) |
| Harmonized System (HS) code | 84733080 |
