MINI DISPLAYPORT TO DISPLAYPORT
Introduction
Connect your Mini-DisplayPort-equipped computer to a standard DisplayPort monitor
The MDP2DPMM4M 4-meter Mini DisplayPort® to DisplayPort Adapter Cable, features a Mini DisplayPort (male) connector on one end, and a DisplayPort (male) connector on the other, allowing you to connect any Mini DisplayPort-equipped laptop (including the Mac® family of products) to an HDTV, monitor or projector that uses a standard DisplayPort connection.
Please Note : Newer laptop and desktop computers (e.g. Apple®) come equipped with Thunderbolt™ ports only. Our Mini DP to DP Cables can be connected to the Thunderbolt ports, enabling you to connect your DP compatible displays.
Specifications
| Features | |
|---|---|
| Cable shielding | Aluminum mylar foil |
| Cable rating | CMG (CM) |
| Number of conductors | 19 |
| Product colour | Black |
| Cable length | 4 m |
| Connector 1 | mini DisplayPort |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Jacket material | Polyvinyl chloride (PVC) |
| AWG wire size | 32 |
| Bandwidth | 21600 MB/s |
| Maximum resolution | 3840 x 2400 pixels |
| Supported graphics resolutions | 3840 x 2400, 2560 x 1600 (WQXGA) |
| Maximum refresh rate | 120 Hz |
| Multi-Stream Transport (MST) | Yes |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Certificates | |
| Compliance certificates | RoHS, CE |
| Weight & dimensions | |
| Weight | 136 g |
| Package weight | 145 g |
| Package width | 200 mm |
| Package depth | 220 mm |
| Package height | 29 mm |
| Packaging data | |
| Package weight | 145 g |
| Weight | 136 g |
| Package width | 200 mm |
| Package depth | 220 mm |
| Package height | 29 mm |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Harmonized System (HS) code | 84733080 |
| Compliance certificates | RoHS, CE |
| Logistics data | |
| Products per master (outer) case | 40 pc(s) |
| Master (outer) case width | 370 mm |
| Master (outer) case length | 418 mm |
| Master (outer) case height | 280 mm |
| Harmonized System (HS) code | 84733080 |
