EU Product - OPIC HDMI 4K CLE
Introduction
HDMI 2.0 Support 4K/60Hz 4:4:4 18Gbps, HDR 12bit, HDCP2.2, 3D & ARC. Slim size of 4.0mm.
Typical installation:
Places where high resolution is required on long distance.
Tensile Strength (Pull resistance): 20 kg.
Specifications
| Features | |
|---|---|
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum refresh rate | 60 Hz |
| Product colour | Black |
| Cable length | 5 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Cable material | Fiber optic |
| HDMI version | 2.0 |
| Data transfer rate | 18 Gbit/s |
| 3D | Yes |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Cable jacket material | Low smoke zero halogen (LSZH) |
| HDCP version | 2.2 |
| Extended display identification data (EDID) | Yes |
| Bending radius (min) | 2 cm |
| Connector housing material | Metal |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 °C |
| Weight & dimensions | |
| Weight | 149 g |
| Cable diameter | 4 mm |
| Package weight | 160 g |
| Package width | 184 mm |
| Package depth | 180 mm |
| Package height | 36 mm |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package weight | 160 g |
| Package width | 184 mm |
| Package depth | 180 mm |
| Package height | 36 mm |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Width | 184 mm |
| Height | 36 mm |
| Depth | 180 mm |
