Part No:R1304WFTZSR
Stock:6 In Stock
EAN Code:5032037247016
5-7 days delivery
100% Customer
Secure Payment
Intel® Virtualization Technology for Directed I/O (VT-d) Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments. TPM Version TPM (Trusted Platform Module) is a component that provides hardware level security upon system boot-up via stored security keys, passwords, encryption and hash functions. Integrated BMC with IPMI IPMI (Intelligent Platform Management Interface) is a standardized interface used for out-of-band management of computer systems. The integrated BMC (Baseboard Management Controller) is a specialized microcontroller that enables IPMI. Intel® Rapid Storage Technology Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology. Riser Slot 1: Included Slot Configuration(s) This is the configuration of the installed riser card for this specific slot for systems that ship with risers pre-installed. Riser Slot 2: Included Slot Configuration(s) This is the configuration of the installed riser card for this specific slot for systems that ship with risers pre-installed. Integrated Graphics Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card. RAID Configuration RAID (Redundant Array of Independent Disks) is a storage technology that combines multiple disk drive components into a single logical unit, and distributes data across the array defined by RAID levels, indicative of the level of redundancy and performance required. Intel® Remote Management Module Support The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC). Connector for Intel® Integrated RAID Module Internal IO expansion module indicates a mezzanine connector on Intel® Server Boards that supports a variety of Intel(r) I/O Expansion Modules using a x8 PCI Express* interface. These modules are either RoC (RAID-on-Chip) or SAS (Serial Attached SCSI) modules that are not used for external connectivity through the rear I/O panel. PCIe OCuLink Connectors (NVMe support) Onboard PCIe OCuLink connectors provide direct-attach NVMe SSD support. Max # of UPI Links Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI. Intel® Node Manager Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting. Intel® Optane™ Persistent Memory Supported Intel® Optane™ persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance. Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads – from cloud, databases, in-memory analytics, virtualization, and content delivery networks.
| Hard drive | |
|---|---|
| RAID levels | 0, 1, 10 |
| Hot-swap HDD bays | Yes |
| Software | |
| Compatible operating systems | VMware*|Ubuntu* |
| Processor | |
| Built-in processor | No |
| Processor socket | LGA 3647 (Socket P) |
| Number of processors supported | 2 |
| Motherboard chipset | Intel® C624 |
| Compatible processor series | Intel® Xeon® |
| Processor manufacturer | Intel |
| Design | |
| Product codename | Wolf Pass |
| Rack-Friendly board | Yes |
| LED indicators | Yes |
| Heat sink included | Yes |
| Heat sink | (2) 1U Standard Heat Sink FXXCA78X108HS |
| Product colour | Grey, Black |
| Chassis type | Rack (1U) |
| Memory | |
| Supported memory types | DDR4-SDRAM |
| Number of DIMM slots | 24 |
| Maximum internal memory | 6000 GB |
| Storage | |
| Number of storage drives supported | 6 |
| RAID levels | 0, 1, 10 |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Performance | |
| Intel Rapid Storage Technology | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Integrated BMC with IPMI | Yes |
| Compatible operating systems | VMware*|Ubuntu* |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| USB ports quantity | 5 |
| Serial ports quantity | 2 |
| Number of SATA connectors | 10 |
| Ethernet LAN (RJ-45) ports | 3 |
| Expansion slots | |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCI Express x24 Riser Super slots | 1 |
| PCI Express OCuLink connectors (NVMe support) | 4 |
| Features | |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Integrated BMC with IPMI | Yes |
| Compatible operating systems | VMware*|Ubuntu* |
| Harmonized System (HS) code | 8473305100 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Number of UPI links | 2 |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Product codename | Wolf Pass |
| Technical details | |
| USB ports quantity | 5 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| Number of storage drives supported | 6 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Rack-Friendly board | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Integrated BMC with IPMI | Yes |
| Heat sink included | Yes |
| Heat sink | (2) 1U Standard Heat Sink FXXCA78X108HS |
| CPU configuration (max) | 2 |
| Chassis type | Rack (1U) |
| Target market | Mainstream |
| Supported board | Intel Server Board S2600WFTR |
| Status | Launched |
| Riser slot 2 number of lanes | 24 |
| Riser slot 1 number of lanes | 24 |
| Launch date | Q1'22 |
| Extended warranty available for purchase (select countries) | Yes |
| PCI Express x24 Riser Super slots | 1 |
| Harmonized System (HS) code | 8473305100 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Colour | |
| Product colour | Grey, Black |
| Indication | |
| LED indicators | Yes |
| Logistics data | |
| Harmonized System (HS) code | 8473305100 |
| Processor special features | |
| Intel Rapid Storage Technology | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Processor ARK ID | 132547 |
| Power | |
| Redundant power supply (RPS) support | Yes |
| Power supply type | AC |
| Power supply | 1300 W |
| Number of power supply units | 1 |
| Thermal Design Power (TDP) | 165 W |
| Weight & dimensions | |
| Width | 430 mm |
| Other features | |
| On-board graphics card | No |
| CPU configuration (max) | 2 |
| Product codename | Wolf Pass |
| Target market | Mainstream |
| Supported board | Intel Server Board S2600WFTR |
| Status | Launched |
| Riser slot 2 number of lanes | 24 |
| Riser slot 1 number of lanes | 24 |
| Launch date | Q1'22 |
| Extended warranty available for purchase (select countries) | Yes |
