MICRO HDMI TO VGA ADAPTER
Introduction
Connect a Micro HDMI® equipped Smartphone or Tablet PC to your VGA Display, or Projector
The MCHD2VGAE2 HDMI® Micro to VGA adapter/converter actively converts an HDMI® Micro video signal from your smartphone, Ultrabook, or tablet PC onto a VGA projector, or display. The Micro HDMI to VGA adapter is intended for displaying user generated content such as presentations, documents, and work sheets onto a VGA projector or monitor.
The HDMI Micro/VGA adapter supports video resolutions up to full 1080p, making it a convenient option for high-definition applications, and features a compact design with no external power source, which ensures a portable solution that's easy to carry as an accessory.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
Specifications
| Features | |
|---|---|
| Converter type | Active video converter |
| Product colour | Black |
| Maximum resolution | 1920 x 1200 pixels |
| Certification | CE, FCC, REACH |
| Maximum refresh rate | 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 40 - 85% |
| Certificates | |
| Certification | CE, FCC, REACH |
| Compliance certificates | RoHS |
| Other features | |
| Width | 45 mm |
| Height | 15 mm |
| Depth | 255 mm |
| Weight & dimensions | |
| Width | 45 mm |
| Height | 15 mm |
| Depth | 255 mm |
| Weight | 25.3 g |
| Package width | 199 mm |
| Package depth | 112 mm |
| Package height | 18 mm |
| Package weight | 33 g |
| Packaging data | |
| Package width | 199 mm |
| Package depth | 112 mm |
| Package height | 18 mm |
| Package weight | 33 g |
| Technical details | |
| Harmonized System (HS) code | 84733080 |
| Compliance certificates | RoHS |
| Logistics data | |
| Master (outer) case width | 420 mm |
| Master (outer) case length | 415 mm |
| Master (outer) case height | 435 mm |
| Products per master (outer) case | 240 pc(s) |
| Harmonized System (HS) code | 84733080 |
