F12 LOW NOISE FAN
Introduction
The F12 case fans are exceptionally quiet and cost effective solutions with efficient cooling performance. The patented low noise impeller maximizes the volume of airflow to offer optimal performance at relatively low fan speed.
Specifications
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 3-pin |
| Rotational speed (min) | 0 RPM |
| Rotational speed (max) | 1350 RPM |
| Noise level | 0.3 sone |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Type | Fan |
| Operating temperature (T-T) | 0 - 40 °C |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Maximum airflow | 53 cfm |
| Minimum air pressure | 1 mmH2O |
| Airflow | 90.1 m³/h |
| Number of fans | 1 fan(s) |
| Quantity per pack | 1 pc(s) |
| Design | |
| Fan connector | 3-pin |
| Number of fans | 1 fan(s) |
| Product colour | Black |
| Cable length | 0.4 m |
| Illumination LED | No |
| Display type | Not applicable |
| Technical details | |
| Type | Fan |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Maximum airflow | 53 cfm |
| Minimum air pressure | 1 mmH2O |
| Airflow | 90.1 m³/h |
| Number of fans | 1 fan(s) |
| Cable length | 0.4 m |
| Fan connector | 3-pin |
| Illumination LED | No |
| Ports & interfaces | |
| Fan connector | 3-pin |
| Power | |
| Starting voltage | 2.7 V |
| Voltage | 12 V |
| Rated current | 0.12 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Package depth | 27 mm |
| Package width | 123 mm |
| Package height | 123 mm |
| Width | 120 mm |
| Package weight | 130 g |
| Depth | 120 mm |
| Height | 25 mm |
| Weight | 107 g |
| Cable length | 0.4 m |
| Packaging data | |
| Package depth | 27 mm |
| Package width | 123 mm |
| Package height | 123 mm |
| Package weight | 130 g |
| Package type | Box |
| Packaging content | |
| Package type | Box |
| Other features | |
| Country of origin | Hong Kong |
| Harmonized System (HS) code | 84733080 |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
