P8 MAX 80MM FAN
Introduction
ARCTIC P8 Max - High-Performance 80 mm PWM Fan. Type: Fan, Fan diameter: 8 cm, Noise level: 0.6 sone, Airflow: 67.96 m³/h, Bearing type: Dual ball bearing. Height: 80 mm. Product colour: Black
Specifications
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Noise level | 0.6 sone |
| Bearing type | Dual ball bearing |
| Type | Fan |
| Operating temperature (T-T) | 0 - 40 °C |
| Fan diameter | 8 cm |
| Maximum airflow | 40 cfm |
| Airflow | 67.96 m³/h |
| Rack capacity | 2U |
| Number of fans | 1 fan(s) |
| Quantity per pack | 1 pc(s) |
| Number of fan blades | 5 |
| Fan bearing technology | Double ball bearing |
| Fan static pressure | 5.3 mmH2O |
| Fan speed (min) | 500 RPM |
| Fan speed (max) | 5000 RPM |
| Fan's mean time to failure (MTTF) | 500000 h |
| Design | |
| Fan connector | 4-pin |
| Rack capacity | 2U |
| Number of fans | 1 fan(s) |
| Product colour | Black |
| Cable length | 0.4 m |
| Illumination LED | No |
| Number of fan blades | 5 |
| Display type | Not applicable |
| Technical details | |
| Type | Fan |
| Fan diameter | 8 cm |
| Maximum airflow | 40 cfm |
| Airflow | 67.96 m³/h |
| Rack capacity | 2U |
| Number of fans | 1 fan(s) |
| Cable length | 0.4 m |
| Fan connector | 4-pin |
| Illumination LED | No |
| Ports & interfaces | |
| Fan connector | 4-pin |
| Power | |
| Starting voltage | 3.2 V |
| Fan voltage | 12 V |
| Fan current | 0.19 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Fan dimensions (W x D x H) | 80 x 80 x 25 mm |
| Package depth | 82.5 mm |
| Package width | 82.5 mm |
| Package height | 26 mm |
| Fan weight | 84 g |
| Package weight | 89 g |
| Height | 80 mm |
| Cable length | 0.4 m |
| Packaging data | |
| Package depth | 82.5 mm |
| Package width | 82.5 mm |
| Package height | 26 mm |
| Package weight | 89 g |
| Packaging content | |
| Screws included | Yes |
| Mounting kit | Yes |
| Other features | |
| Country of origin | Hong Kong |
