Introduction
The ThinkPad Thunderbolt 3 Workstation Dock Gen 2 (40AN) turns your ThinkPad Mobile Workstation into a productivity powerhouse, adding support for multi 4K displays, optimized one cable charging, a slew of expansion ports, and advanced network manageability features.
Specifications
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| Host interface | Thunderbolt 3 |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 2 |
| Microphone in | No |
| Headphone outputs | 0 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Maximum digital resolution | 3840 x 2160 pixels |
| Product colour | Black |
| Card reader integrated | No |
| Built-in speaker(s) | No |
| Brand compatibility | Lenovo |
| Compatibility | ThinkPad L390 (20NR, 20NS), ThinkPad L390 Yoga (20NT. 20NU), Thinkpad L490 (20Q5,20Q6), Thinkpad L590 (20N7,20N8), Thinkpad E590 20NB, 20NC), Thinkpad E490 (20N8, 20N9), Thinkpad E490s (20NG) |
| Certification | CE-EMC, TUV Mark,KCC,Serbia Kvalitet, CU EAC |
| Audio | |
| Built-in speaker(s) | No |
| Technical details | |
| Product colour | Black |
| Brand compatibility | Lenovo |
| Compatibility | ThinkPad L390 (20NR, 20NS), ThinkPad L390 Yoga (20NT. 20NU), Thinkpad L490 (20Q5,20Q6), Thinkpad L590 (20N7,20N8), Thinkpad E590 20NB, 20NC), Thinkpad E490 (20N8, 20N9), Thinkpad E490s (20NG) |
| Harmonized System (HS) code | 84733020 |
| User guide | Yes |
| Storage | |
| Card reader integrated | No |
| Multimedia | |
| Built-in speaker(s) | No |
| Software | |
| Windows operating systems supported | Windows 10 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Weight | 525 g |
| Width | 220 mm |
| Depth | 80 mm |
| Height | 30 mm |
| Package weight | 1.9 kg |
| Package width | 270 mm |
| Package depth | 195 mm |
| Package height | 85 mm |
| Design | |
| Windows operating systems supported | Windows 10 |
| Product colour | Black |
| Certification | CE-EMC, TUV Mark,KCC,Serbia Kvalitet, CU EAC |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package weight | 1.9 kg |
| Package width | 270 mm |
| Package depth | 195 mm |
| Package height | 85 mm |
| Packaging content | |
| User guide | Yes |
| Quick start guide | Yes |
| Cables included | AC, Thunderbolt |
| AC adapter included | Yes |
| Quantity per pack | 1 pc(s) |
| Certificates | |
| Certification | CE-EMC, TUV Mark,KCC,Serbia Kvalitet, CU EAC |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
