ATP100 Firewall with 1Yr bundle (Version 2)
Introduction
Next-Gen Firewall for SMBs
The Zyxel ZyWALL ATP100/200/500/800 is an Advanced Threat Protection Firewall Series dedicated for small and medium businesses, empowered by cloud intelligence to level up network protection, especially in tackling unknown threats. The ZyWALL ATP Firewall Series not only supports all Zyxel security service such as Web security, Application Security, Malware Blocker, Reputation Filter, etc., but also sandboxing and SecuReporter, and, last but not least, an infographic dashboard, delivering high performance and ensuring comprehensive protection as a self-evolving solution.
Specifications
| Data transmission | |
|---|---|
| SSL performance | 10 transactions/sec |
| IPSec VPN throughput | 40 Gbit/s |
| Maximum connections (SPI) | 1000 |
| HTTPS encryption | Yes |
| Maximum data transfer rate | 1 Gbit/s |
| Firewall throughput | 1 Gbit/s |
| VPN throughput | 0.3 Gbit/s |
| Maximum data transfer rate | 1000 Mbit/s |
| Firewall throughput | 1000 Mbit/s |
| VPN throughput | 300 Mbit/s |
| Performance | |
| Mean time between failures (MTBF) | 989810.8 h |
| Concurrent users | 10 user(s) |
| Concurrent connections | 300000 |
| Heat dissipation | 42.65 BTU/h |
| Certification | FCC Part 15 (Class B), CE (Class B), RCM (Class B), BSMI, LVD |
| Network | |
| Active TCP connections (max) | 300000 |
| VPN tunnels quantity | 40 |
| Number of VLANs | 8 |
| Security | |
| Security algorithms | IPSec, SSL/TLS |
| Content filtering | 1 |
| VPN support | IKEv2, IPSec, SSL, L2TP/IPSec |
| Stateful Packet Inspection (SPI) | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| SFP module slots quantity | 1 |
| Connectivity technology | Wired |
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet DMZ ports quantity | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Console port | RJ-45 |
| Number of console ports | 1 |
| Design | |
| Built-in fan | Yes |
| Power | |
| Input current | 2 A |
| Power consumption (typical) | 12.5 W |
| Power consumption (max) | 12.5 W |
| Certificates | |
| Certification | FCC Part 15 (Class B), CE (Class B), RCM (Class B), BSMI, LVD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Dimensions (WxDxH) | 216 x 143 x 33 mm |
| Weight | 850 g |
| Packaging data | |
| Package width | 284 mm |
| Package height | 190 mm |
| Package depth | 100 mm |
| Package weight | 1.4 kg |
| Packaging content | |
| Cables included | LAN (RJ-45), RS-232 |
| Technical details | |
| Concurrent users | 10 user(s) |
| Concurrent connections | 300000 |
| Heat dissipation | 42.65 BTU/h |
| Harmonized System (HS) code | 85176990 |
| Endurance | |
| Mean time between failures (MTBF) | 989810.8 h |
| Other features | |
| Maximum data transfer rate | 1000 Mbit/s |
| Firewall throughput | 1000 Mbit/s |
| VPN throughput | 300 Mbit/s |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
