EU Product - EMC Dell Networking S4148F-ON - Switch - L3 - managed
Introduction
Flexible, powerful and optimized
Designed for flexibility and high performance for today's demanding modern workloads and applications.
Specifications
| Management features | |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| MIB support | IP MIB, IP Forward MIB, Host Resources MIB, IF MIB, LLDP MIB, Entity MIB, LAG MIB, Dell-Vendor MIB, TCP MIB, UDP MIB, SNMPv2 MIB |
| Switch layer | L2/L3 |
| Configuring Location Settings (CLI) | Yes |
| Ports & interfaces | |
| SFP+ module slots quantity | 48 |
| QSFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | No |
| Gigabit Ethernet (copper) ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| Console port | RJ-45/Micro-USB |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.3 |
| VLAN support | Yes |
| Link aggregation | Yes |
| Flow control support | Yes |
| 10G support | Yes |
| Virtual LAN features | Tagged VLAN |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Data transmission | |
| Jumbo frames | 9416 |
| Throughput | 1320 Mpps |
| Packet buffer memory | 12 MB |
| MAC address table | 272000 entries |
| Switching capacity | 1760 Gbit/s |
| Jumbo frames support | Yes |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | CLI, SNMP, REST, API’s |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Rack mounting | Yes |
| Ventilation system | Front-to-back airflow |
| Performance | |
| Internal memory | 4000 MB |
| Built-in processor | Yes |
| Packet buffer memory | 12 MB |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power consumption (max) | 370 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 200 W |
| Number of power supply units | 2 |
| Power connector | AC-in jack |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| Virtual LAN features | |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| Weight & dimensions | |
| Width | 431 mm |
| Depth | 457 mm |
| Height | 44 mm |
| Weight | 9.46 kg |
| Technical details | |
| Form factor | 1U |
| Product colour | Black |
| Rack mounting | Yes |
| Built-in processor | Yes |
| Memory | |
| Packet buffer memory | 12 MB |
| Internal memory | 4000 MB |
| Mobile network | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
