STARTECH.COM PEX8S1050LP STARTECH.COM 8-PORT PCI EXPRESS SERIAL CARD

*Image accuracy is not guaranteed. Please do not rely on the image for your purchase.. ** All heavy items above 25KG will be charged shipping cost as per actual. Please contact us for a shipping quote before placing order

PEX8S1050LP STARTECH.COM 8-PORT PCI EXPRESS SERIAL CARD

Part No:PEX8S1050LP

Stock:2 In Stock

EAN Code:0065030886574

£164.57 Excl. VAT

£197.48 Incl. VAT

price matchPrice Match
Guarantee
Delivery1-2 days delivery
customer satisfaction100% Customer
Satisfaction
secure paymentSecure Payment
Options
Accept Purchase orders
We accept Purchase Orders from Education Sector, Hospitals, Police, Councils and more.Choose Payment Option "Purchase Order" While placing your order online.

Any Questions?

If you have any questions about price and availability of the product, please drop us a query below:

8-PORT PCI EXPRESS SERIAL CARD

Introduction

Low Profile Serial Card | Full Profile Brackets Incl | 921.4Kbps | Windows and Linux

Add eight RS-232 DB9 serial ports to your desktop computer, through two PCIe expansion card slots. This PCI express serial card, with two breakout cables, provides you with multiple ports to connect a wide variety of serial peripherals, at speeds of up to 921.4Kbps.Connect your Peripherals with 8 Serial PortsThe PCI express serial port card makes it easy to add serial ports to connect your peripherals including printers, scanners, credit/debit card readers, PIN pads and modems, industrial controls and more. The 8 port PCIe serial card includes 2 breakout cables - each with 4 DB9 connectors.Versatile UseThe low profile PCIe serial card is the ideal choice for adding serial ports, even when space is at a premium. The DB9 serial card is designed to fit into small form factor and standard computer cases. The card comes pre-configured with a low-profile bracket, and includes two optional full-profile brackets, so installation is easy regardless of the case form factor.Maximum CompatibilityWith broad OS support, including for Windows and Linux, this PCI Express card is easy to integrate into mixed environments.PEX8S1050LP?is backed by a StarTech.com lifetime warranty and free lifetime technical support.

The StarTech.com Advantage

- 8 PORT SERIAL CARD: Serial controller card w/ 16C1050 UART based on the Systembase SB16C1058PCI, w/15kV ESD, 8x DB9 ports, bi-directional RS232 speeds up to 921.6Kbps per port & 256 byte FIFO buffer
- OPTIONAL CONFIGURABLE POWER: Multiport serial card provides 12v/5v, or none on pin 9 w/up to 3A total shared; 2 (1xDB44 to 4xDB9) breakout cables incl; Hex nuts incl for opt screw or nut DB9 interface
- COMPATABILITY: 2 low profile brackets for PCI-e 1x card; Fully compliant w/ PCI Express Base Spec, Revision 1.0a/1.1; Supports Windows (incl. XP and up) and Linux; For low profile desktop/servers

Specifications

Ports & interfaces
InternalYes
Output interfaceSerial
Serial interface typeRS-232
Serial ports quantity8
Host interfacePCIe
Expansion card form factorFull-height / Low-profile
Technical details
ChipsetASMEDIA - ASM1083, SYSTEMBASE - SB16C1058PCI
FIFO (First In, First Out)256 B
Sustainability certificatesRoHS
Performance
Stop bits1, 1.5, 2
Data bits5, 6, 7, 8
Baud rate926.1 Kbit/s
ChipsetASMEDIA - ASM1083, SYSTEMBASE - SB16C1058PCI
FIFO (First In, First Out)256 B
Flow control supportYes
Product colourYellow
Harmonized System (HS) code84733020
Certificates
CertificationCE, FCC, TAA
Colour
Product colourYellow
Design
InternalYes
Product colourYellow
CertificationCE, FCC, TAA
Features
Stop bits1, 1.5, 2
Data bits5, 6, 7, 8
Baud rate926.1 Kbit/s
ChipsetASMEDIA - ASM1083, SYSTEMBASE - SB16C1058PCI
FIFO (First In, First Out)256 B
Flow control supportYes
Parity bitEven, No, Odd
Flow Control typeRTS/CTS, XON/XOFF
Harmonized System (HS) code84733020
Operational conditions
Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)-20 - 85 °C
Operating relative humidity (H-H)5 - 95%
System requirements
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019
Weight & dimensions
Width22 mm
Depth145 mm
Height60 mm
Weight116 g
Package width190 mm
Package depth290 mm
Package height70 mm
Package weight750 g
Packaging data
Mounting brackets includedYes
Package width190 mm
Package depth290 mm
Package height70 mm
Package weight750 g
Cables includedSerial
User guideYes
Quantity1
Logistics data
Products per master (outer) case14 pc(s)
Master (outer) case width400 mm
Master (outer) case length510 mm
Master (outer) case height315 mm
Harmonized System (HS) code84733020
Packaging content
Mounting brackets includedYes
Cables includedSerial
User guideYes
Quantity1
Other features
ChipsetASMEDIA - ASM1083, SYSTEMBASE - SB16C1058PCI
Flow control supportYes
