EU Product - 3+1 por US 3.0 PCIe crd
Introduction
This production is a single chip USB 3.0 Host controller which enables a PCI Express equipped platform to interface with USB Super-Speed(5Gbps),High-Speed(480Mbps),Full-Speed(12Mbps), and Low-Speed (1.5Mbps) devices, Users can easy to connect your Mass Storage, Printer, Scanner , Hub, Camera and any other USB Devices to used. low profile bracket included.
Specifications
| Ports & interfaces | |
|---|---|
| Internal | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Output interface | USB 3.2 Gen 1 (3.1 Gen 1) |
| Host interface | PCIe |
| Technical details | |
| Chipset | Via VL805 |
| Bandwidth | 5 Gbit/s |
| Quantity per pack | 1 pc(s) |
| Performance | |
| Chipset | Via VL805 |
| Bandwidth | 5 Gbit/s |
| Design | |
| Internal | Yes |
| Features | |
| Chipset | Via VL805 |
| Bandwidth | 5 Gbit/s |
| Power | |
| Output voltage | 5 V |
| Output current | 0.9 A |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| System requirements | |
| Windows operating systems supported | Yes |
| Weight & dimensions | |
| Width | 90 mm |
| Depth | 67 mm |
| Weight | 66 g |
| Package width | 145 mm |
| Package depth | 112 mm |
| Package height | 28 mm |
| Package weight | 76 g |
| Packaging data | |
| Package width | 145 mm |
| Package depth | 112 mm |
| Package height | 28 mm |
| Package weight | 76 g |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Chipset | Via VL805 |
