*Image accuracy is not guaranteed. Please do not rely on the image for your purchase.. ** All heavy items above 25KG will be charged shipping cost as per actual. Please contact us for a shipping quote before placing order
Part No:SV431HU34K6
Stock:4 In Stock
EAN Code:0065030882019
KVM with USB | TAA Compliant | USB 3.0 Hub | HDMI 2.0 | Digital & Analog AudioThis 4 port KVM switch combines 4K (60Hz) digital display capabilities with control of our connected computers.4K 60Hz Picture and Full Audio SupportThe HDMI KVM switch supports resolutions up to 4K at 60Hz. It drives one large monitor at the full 4K resolution. Includes EDID and HDCP signal emulation so monitors always remain synced for faster switching times, and desktop settings are maintained to avoid disrupting your workflow.With support for digital audio (with supporting displays and sources) and separate 3.5 mm stereo audio, the HDMI 2.0 KVM switch delivers full audio compatibility.Integrated USB HubThe integrated USB 3.0 hub shares two peripherals (in addition to keyboard and mouse) among attached computers as if they were directly connected to your host computer, eliminating the cost of duplicate devices such as printers and scanners.Windows, Mac & Linux CompatibleWhile supporting Windows, this HDMI KVM switch is also compatible with Mac and Linux operating systems.Easy to OperateThe front-panel pushbuttons make it easy to switch between systems and activate the auto-scan feature. The hotkey functionality makes accessing each system quickly, while a buzzer sound confirms the switch.StarTech.com offers a wide selection of high-quality KVM switches and KVM-related products to help you access your systems more efficiently without the expense and clutter of extra keyboards, mice, and monitors.This 4 port HDMI KVM switch is backed by a 2-year warranty and free lifetime technical support.The StarTech.com Advantage
Technical details | |
---|---|
Product colour | Black |
Scan interval | 3,8,15,30 s |
Push button | Yes |
On Screen Display (OSD) | No |
LED indicators | Yes |
Hot keys | Yes |
IP control | No |
USB hub | Yes |
Video | |
HD type | 4K Ultra HD |
Maximum resolution | 3840 x 2160 pixels |
Ports & interfaces | |
Console USB ports quantity | 4 |
Console ports | 3.5mm headphone, 3.5mm mic, HDMI, USB A |
Number of microphone inputs | 5 |
HDMI version | 2.0 |
Number of computers controlled | 1 |
Keyboard port type | USB |
Mouse port type | USB |
Video port type | HDMI |
Audio connections | Yes |
Headphone outputs | 5 |
HDMI ports quantity | 5 |
DC-in jack | Yes |
USB hub | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
Performance | |
Daisy chain | No |
Chipset | Genesys Logic - GL3523 |
Data transfer rate (max) | 5 Gbit/s |
HD type | 4K Ultra HD |
Maximum resolution | 3840 x 2160 pixels |
Scan interval | 3,8,15,30 s |
Audio channels | 7.1 |
Design | |
Mean time between failures (MTBF) | 143000 h |
Product colour | Black |
Push button | Yes |
LED indicators | Yes |
Hot keys | Yes |
Certification | CE, FCC, RoHS |
Housing material | Steel |
Display | |
Built-in display | No |
On Screen Display (OSD) | No |
Power | |
Input current | 1 A |
Output current | 3 A |
Power plug type | Type M |
Compatible power plug types | EU, UK, US |
Output voltage | 12 V |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 36 W |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -10 - 60 °C |
Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions | |
Width | 130 mm |
Depth | 220 mm |
Height | 44 mm |
Weight | 1.1 kg |
Package width | 212 mm |
Package depth | 409 mm |
Package height | 87 mm |
Package weight | 1.8 kg |
Packaging data | |
Package width | 212 mm |
Package depth | 409 mm |
Package height | 87 mm |
Package weight | 1.8 kg |
Packaging content | |
Rubber feet | Yes |
Manual | Yes |
Certificates | |
Certification | CE, FCC, RoHS |
Logistics data | |
Master (outer) case width | 545 mm |
Master (outer) case length | 438 mm |
Master (outer) case height | 258 mm |
Products per master (outer) case | 6 pc(s) |
Harmonized System (HS) code | 85176200 |
Other features | |
Push button | Yes |
Hot keys | Yes |
IP control | No |
