EU Product - QL-820NW
Introduction
Brother QL-820NW. Print technology: Direct thermal, Maximum resolution: 300 x 600 DPI, Print speed: 176 mm/sec. Connectivity technology: Wired & Wireless, Wi-Fi, Bluetooth, Bluetooth version: 5.2, USB port. Tape type: DK. Product colour: Black, White
Specifications
| Print quality | |
|---|---|
| Maximum resolution | 300 x 600 DPI |
| Maximum printing width | 6.1 cm |
| Printing | |
| Print speed | 110 lpm |
| Print speed | 176 mm/sec |
| Maximum resolution | 300 x 600 DPI |
| Maximum printing width | 6.1 cm |
| Print technology | Direct thermal |
| Display | |
| Display | LCD |
| Network | |
| Wi-Fi | Yes |
| Memory | |
| Internal memory | 6 MB |
| Paper handling | |
| Maximum label width | 6.2 cm |
| Ports & interfaces | |
| Bluetooth profiles | SPP, OPP, HCRP |
| Connectivity technology | Wired & Wireless |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| USB port | Yes |
| Performance | |
| Tape type | DK |
| Built-in barcodes | PDF417, QR Code, Data Matrix, MaxiCode, Code 93, POSTNET, UPC-E, Code 39, Code128UCC, ITF, CODABAR (NW-7), EAN13, GS1 DataBar, GS1 DataBar Truncated, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded Stacked |
| Internal memory | 6 MB |
| Bitmap fonts | Brougham, Brussels, Helsinki, Letter Gothic Bold, San Diego |
| Design | |
| Display | LCD |
| Product colour | Black, White |
| Technical details | |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Windows operating systems supported | Windows 10, Windows 11, Windows 8.1 |
| Product colour | Black, White |
| Tape type | DK |
| Built-in barcodes | PDF417, QR Code, Data Matrix, MaxiCode, Code 93, POSTNET, UPC-E, Code 39, Code128UCC, ITF, CODABAR (NW-7), EAN13, GS1 DataBar, GS1 DataBar Truncated, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded Stacked |
| Maximum label width | 6.2 cm |
| Compliance certificates | Mfi |
| System requirements | |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Windows operating systems supported | Windows 10, Windows 11, Windows 8.1 |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 234 mm |
| Height | 145 mm |
| Weight | 1.16 kg |
| Packaging content | |
| Cables included | USB, AC |
