VS WIFI6 WIRELESS MODULE FOR VIEWBOARD
Introduction
Viewsonic VB-WIFI-001. Connectivity technology: Wireless, Host interface: USB, Interface: WLAN / Bluetooth. Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi band: Dual-band (2.4 GHz / 5 GHz). USB powered. Product colour: Black
Specifications
| Ports & interfaces | |
|---|---|
| Internal | No |
| Interface | WLAN / Bluetooth |
| Host interface | USB |
| Connectivity technology | Wireless |
| USB connector form factor | Straight |
| Wireless LAN features | |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Technical details | |
| Product colour | Black |
| Harmonized System (HS) code | 8517620000 |
| Network | |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Bluetooth version | 5.2 |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Bluetooth | Yes |
| Design | |
| Product colour | Black |
| Certification | FCC, FCC ID, IC ID, CE, RCM |
| Internal | No |
| Component for | PC |
| Power | |
| Output voltage | 5 V |
| Power consumption (typical) | 4.5 W |
| USB powered | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 99 mm |
| Depth | 11 mm |
| Height | 77 mm |
| Weight | 30 g |
| Package width | 90 mm |
| Package depth | 157 mm |
| Package height | 16 mm |
| Package weight | 80 g |
| Packaging data | |
| Package width | 90 mm |
| Package depth | 157 mm |
| Package height | 16 mm |
| Package weight | 80 g |
| Certificates | |
| Certification | FCC, FCC ID, IC ID, CE, RCM |
| Other features | |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Harmonized System (HS) code | 8517620000 |
| Logistics data | |
| Products per master (outer) case | 1 pc(s) |
| Pallet gross width | 175 cm |
| Pallet gross length | 114 cm |
| Pallet gross height | 79.9 cm |
| Harmonized System (HS) code | 8517620000 |
