Part No:561235-UK
Stock:19 In Stock
EAN Code:0766623561235
60 Watts of Power for the Internet of things (IoT)!
IEEE 802.3bt Compatible
The Intellinet Network Solutions Gigabit High-Power PoE Injector provides up to 60 W using all four pairs of twisted-pair Cat5 or Cat6 cabling to support IoT applications such as lighting, sensors and building automation. Nurse call systems require 30 to 50 watts of power. Point-of-sale card readers & printers need up to 60 watts. Lighting fixtures and controllers require 40 to 50 watts. Thin clients draw up to 50 watts. The IEEE 802.3bt Ultra PoE standard is an excellent solution for bringing power to these important, critical systems. As many new IEEE 802.3bt powered devices enter the market, you'll be ready for them with an Intellinet Network Solutions Gigabit High-Power PoE Injector.
Full Compatibility with Existing IEEE 802.3af/at PoE Powered Devices
The Intellinet Network Solutions Gigabit High-Power PoE Injector allows you to connect your IEEE 802.3af/at-compliant products to a non-PoE LAN switch port. The injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af/at-powered device (PD) to a switch.
Reduced Wiring Costs
It's no longer necessary to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data.
Protect Your Equipment.
Once DC power is connected to your networked equipment through the Cat5e/6 cabling, the Intellinet Network Solutions PoE Injector ensures that your products are protected from power problems like short circuits (short GRND), current overloads and high voltages.
Network | |
---|---|
Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
Duplex system | Full |
Power over Ethernet (PoE) | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet interface type | Gigabit Ethernet |
Power over Ethernet (PoE) voltage | 48 V |
Features | |
Product colour | Black |
Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
Power protection features | Over current, Over voltage, Short circuit |
LED indicators | PoE |
Certification | FCC Class B, CE |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
Power | |
Output current | 1.25 A |
Power consumption (max) | 60 W |
Power over Ethernet (PoE) voltage | 48 V |
Input voltage | 100 - 240 V |
Input frequency | 50/60 Hz |
Technical details | |
Number of products included | 1 pc(s) |
Power over Ethernet (PoE) | Yes |
Input voltage | 100 - 240 V |
Input frequency | 50/60 Hz |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet interface type | Gigabit Ethernet |
Operational conditions | |
Storage temperature (T-T) | -20 - 80 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions | |
Weight | 290 g |
Width | 61 mm |
Depth | 123 mm |
Height | 40 mm |
Packaging content | |
Power cord included | Yes |
Manual | Yes |
Number of products included | 1 pc(s) |
Certificates | |
Certification | FCC Class B, CE |
Indication | |
LED indicators | PoE |
