TP-LINK POE370S 10G POE INJECTOR
Introduction
The Omada PoE++ Injector POE370S fully complies with IEEE 802.3af/at/bt (type 3) standards with up to 60 W power supply.* It can easily expand your network to where there are no power lines or outlets, ideal for connecting PTZ IP Cameras, access points, and LEDs.
Specifications
| Network | |
|---|---|
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u |
| Power over Ethernet (PoE) | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) |
| Features | |
| Wall mountable | Yes |
| Plug and Play | Yes |
| Product colour | Black |
| LED indicators | Yes |
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
| Power consumption (typical) | 60 W |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 154.7 mm |
| Height | 42 mm |
| Technical details | |
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 60 W |
| Ethernet interface type | 10 Gigabit Ethernet |
| Indication | |
| LED indicators | Yes |
