Part No:10G2A1C25EPD-USB-HUB
Stock:10 In Stock
EAN Code:0065030900676
Enable 2.5G ethernet, 100W PD pass-through, and add three USB 3.2 10Gbps ports, using this portable adapterThis USB Type-C Hub with 2.5Gigabit Ethernet and 100W USB Power Delivery Pass-Through adds three USB 3.2 Gen 2 (10Gbps) ports (2x USB-A, 1x USB-C) to a USB-C enabled computer. Connect the USB hub to a USB-C port on a laptop, using the built-in 1ft (30cm) USB-C host cable. Charge a host laptop by connecting the host laptop's USB-C power supply to the USB Power Delivery (PD) 3.0 port. Backward compatibility with USB 2.0 (480Mbps) devices ensures support for a wide range of modern and legacy USB peripherals.2.5 Gigabit EthernetThe USB hub features a 2.5 Gigabit Ethernet adapter. The Ethernet controller is compatible with the IEEE 802.3bz standard (2.5GBASE-T/NBASE-T) and supports Wake-on-LAN (WoL), Jumbo Frames, and V-LAN Tagging. The network adapter enhances network reliability, security, and performance at speeds of up to 10/100/1000/2500Mbps.USB Power Delivery Pass-ThroughThis USB hub features 100W USB Power Delivery 3.0 pass-through (85W laptop charging). Connect a power source to the PD pass-through port to power the connected host device. PD 3.0 features Fast Role Swap (FRS) to prevent USB data disruption when switching power sources (USB-C power adapter to bus power).This Power is dynamically shared across the downstream ports. For added protection to the USB hub and any connected devices, the USB hub features Overcurrent Protection (OCP). OCP prevents faulty USB peripherals from drawing more power than is safely allocated.Plug and PlayThis device is compatible with all major operating systems, including Windows, macOS, ChromeOS, iPadOS, and Android. The Hub is automatically detected, configured, and installed upon connection to a host computer.Enhance Productivity and Device Management with the StarTech.com Connectivity Tools ApplicationDeveloped to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:•USB Event Monitoring Utility: Track and log connected USB devices.•MAC Address Pass-Through Utility: Improve network security.•Wi-Fi Auto Switch Utility: Enable users to quickly access faster network speeds via wired LAN.For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/connectivity-toolsThe StarTech.com Advantage
Ports & interfaces | |
---|---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
Ethernet LAN (RJ-45) ports | 1 |
Microphone in | No |
Connectivity technology | Wired |
USB Power Delivery | Yes |
USB Power Delivery revision | 3.0 |
USB Power Delivery up to | 100 W |
Network | |
Networking standards | IEEE 802.3bz |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Ethernet LAN (RJ-45) ports | 1 |
Performance | |
Product colour | Grey |
Card reader integrated | No |
LED indicators | Activity, Link |
Data transfer rate | 10 Gbit/s |
Housing material | Plastic |
Technical details | |
Product colour | Grey |
Data transfer rate | 10 Gbit/s |
Sustainability compliance | Yes |
Sustainability certificates | CE, RoHS |
Products per master (outer) case | 60 pc(s) |
Master (outer) case width | 500 mm |
Master (outer) case length | 320 mm |
Master (outer) case height | 210 mm |
Storage | |
Card reader integrated | No |
Power | |
Power source type | USB |
USB cable length | 0.305 m |
Indication | |
LED indicators | Activity, Link |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -10 - 70 °C |
Operating relative humidity (H-H) | 10 - 85% |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | CE, RoHS |
Weight & dimensions | |
Weight | 68 g |
Width | 163 mm |
Depth | 34 mm |
Height | 15 mm |
Package weight | 129 g |
Package width | 170 mm |
Package depth | 142 mm |
Package height | 30 mm |
Design | |
Product colour | Grey |
LED indicators | Activity, Link |
Packaging data | |
Package weight | 129 g |
Package width | 170 mm |
Package depth | 142 mm |
Package height | 30 mm |
Packaging content | |
Quick start guide | Yes |
Logistics data | |
Products per master (outer) case | 60 pc(s) |
Master (outer) case width | 500 mm |
Master (outer) case length | 320 mm |
Master (outer) case height | 210 mm |
Other features | |
Chipset | VIA - VL103, VIA - VL822, Realtek - RTL8156B |
