ARISTA NETWORKS SFP-1G-T COMP
Introduction
1000 Mbps (1 Gbps) | Copper | RJ-45 | 100 m (328 ft) | Lifetime Warranty
The AR-SFP-1G-T-ST is an Arista Networks compatible copper transceiver module that has been designed, programmed and tested to work with Arista Networks brand switches and routers. It delivers dependable 1 GbE connectivity over copper cable, for 10/100/1000BASE-TX compliant networks, with a maximum distance of up to 100 m (328 ft).
Technical Specifications:
• Maximum Data Transfer Rate: 1000 Mbps (1 Gbps)
• Type: Copper
• Connection Type: RJ-45
• Maximum Transfer Distance: 100 m (328 ft)
• MTBF: 510,469,759 hours
• Power Consumption: Low power consumption
• Digital Diagnostics Monitoring (DDM): No
This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Specifications
| Performance | |
|---|---|
| SFP transceiver type | Copper |
| Ethernet LAN | Yes |
| Maximum transfer distance | 100 m |
| Duplex system | Full |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Product colour | Silver |
| Hot-swap | Yes |
| Compatible products | SFP-1G-T |
| Mean time between failures (MTBF) | 510469759 h |
| Brand compatibility | Arista |
| Harmonized System (HS) code | 85369010 |
| Features | |
| Product colour | Silver |
| Hot-swap | Yes |
| Compatible products | SFP-1G-T |
| Mean time between failures (MTBF) | 510469759 h |
| Brand compatibility | Arista |
| Certification | CE, FCC, UR, REACH |
| Certificates | |
| Certification | CE, FCC, UR, REACH |
| Compliance certificates | RoHS |
| Network | |
| SFP transceiver type | Copper |
| Maximum data transfer rate | 1250 Mbit/s |
| Interface type | SFP |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Weight & dimensions | |
| Width | 68 mm |
| Depth | 13.7 mm |
| Height | 13.8 mm |
| Weight | 15 g |
| Package depth | 112 mm |
| Package width | 93 mm |
| Package height | 33 mm |
| Package weight | 50 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Package width | 93 mm |
| Package height | 33 mm |
| Hot-swap | Yes |
| Maximum transfer distance | 100 m |
| Duplex system | Full |
| Compatible products | SFP-1G-T |
| Ethernet LAN | Yes |
| Compliance certificates | RoHS |
| Packaging data | |
| Package depth | 112 mm |
| Package width | 93 mm |
| Package height | 33 mm |
| Package weight | 50 g |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Master (outer) case width | 342 mm |
| Master (outer) case length | 422 mm |
| Master (outer) case height | 356 mm |
| Products per master (outer) case | 100 pc(s) |
| Harmonized System (HS) code | 85369010 |
