EU Product - VIGI 4MP ColorPro Turret Network Camera InSight S445S(2.8mm)
Introduction
See True Colors and Details in the Dark
Unveiling every detail in the dark, experiencing clarity and color as vivid as daylight — no extra fill lights needed.
Worry-Free Night Surveillance: Beyond IR & Full-Color
Eliminates general night vision issues like dark corners, glare, and color loss — enjoy worry-free nighttime monitoring.
See Vividly — Even No Extra Fill Lights Needed
Enables full-color imaging in low-light conditions without fill-in lighting, reducing both energy consumption and insect-triggered false alarms for a more eco-friendly solution.
People or Vehicle Triggered Intelligent IR-White Lights Reveal More in Total Darkness
In complete darkness with zero illumination, VIGI’s intelligent infrared-white lights will automatically activate white lights upon detecting people or vehicles, delivering vivid color imaging while deterring intruders.
Accurate Detection with Clear and Extended Vision
Ideal for Low-Light Conditions Where Colors and Details Matter
VIGI AI Detection Technology
People & Vehicle Attributes Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, topwear color, vehicle type, making post-event search faster and easier
Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Specifications
| Performance | |
|---|---|
| Auto pan mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Certification | CE, NTRA, VCCI, KC, IC, BSMI, FCC, IP67, ONVIF |
| Dynamic range | 120 dB |
| Design | |
| Weatherproof | Yes |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| International Protection (IP) code | IP67 |
| Housing material | Metal |
| Camera | |
| Minimum illumination | 0.0005 lx |
| Tilt angle range | 0 - 75° |
| Pan range | 0 - 360° |
| White balance | Area white balance |
| Angle of rotation | 360° |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/3 - 1/10000 s |
| Lens viewing angle, horizontal | 112.5° |
| Lens viewing angle, vertical | 61.4° |
| Lens viewing angle, diagonal | 137° |
| Number of Privacy masking areas | 4 |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 79 mm (1 / 79") |
| Panoramic camera | |
| Sensor type (panoramic camera) | CMOS |
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 52 dB |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 1 |
| Detect distance | 59 m |
| Observe distance | 25 m |
| Recognize distance | 12 m |
| Identify distance | 6 m |
| Fixed focus | Yes |
| Fixed focal length | 2.8 mm |
| Night vision | |
| Night vision | Yes |
| Infra-red wavelength | 850 nm |
| Video | |
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, DNR, Saturation, Sharpness |
| Smart IR | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Bit rate | 64 Kbit/s |
| Back Light Compensation (BLC) | Yes |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Maximum resolution | 2688 x 1520 pixels |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Thermal frame rate (PAL) | 60 Hz |
| Thermal frame rate (NTSC) | 50 Hz |
| Video recording | Yes |
| Audio | |
| Audio input channels | 2.0 channels |
| Audio output channels | 2.0 channels |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Audio system | 2-way |
| Bit rate range | 256 - 6000 Kbit/s |
| Number of microphones | 1 |
| Network | |
| Networking standards | IEEE 802.1x, IEEE 802.3at |
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP |
| Number of simultaneous live view channels | 3 channels |
| Live view | Yes |
| Storage | |
| Cloud services supported | FTP |
| Maximum memory card size | 512 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash) |
| Ports & interfaces | |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Alert notification type | E-mail, Push notification |
| Intelligent Video Surveillance (IVS) system features | Abandoned object, Abnormal sound detection, Intrusion, Line crossing detection, People counting, Region entrance detection, Region exiting detection, Scene change, Vehicle detection |
| Motion sensor | Yes |
| Video motion detection | Yes |
| Password protection type | User |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Human and vehicle targets classification | Yes |
| Digest authentication | Yes |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| Management features | |
| Cloud services supported | FTP |
| Web browser | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Behavior analysis | Audio exception detection, Object removal detection |
| Cloud-managed | Yes |
| Power | |
| Power source type | DC, PoE |
| Power consumption (max) | 17.9 W |
| AC input voltage | 12 V |
| Power consumption (typical) | 15.6 W |
| Certificates | |
| Certification | CE, NTRA, VCCI, KC, IC, BSMI, FCC, IP67, ONVIF |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Package type | Box |
| Width | 111 mm |
| Depth | 111 mm |
| Height | 81.4 mm |
| Weight | 550 g |
| Packaging data | |
| Package type | Box |
| Sustainability | |
| Compliance certificates | CE |
| Packaging content | |
| Number of cameras | 1 |
| Package type | Box |
| Mounting kit | Yes |
| Technical details | |
| Compliance certificates | CE |
| Other features | |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
