POWER CABLE/CORD EU 2PIN/C13FEM
Introduction
PC Power Cord or Monitor Power Cable 5m - Great as a replacement or spare AC power supply cable for printer, TV, server, and more
The Manhattan EU Power Cable CEE 7/7 to C13, 5 m easily connects and extends the reach between a power outlet and a personal computer, monitor, printer, power adapter or other compatible piece of equipment. Ideal for new systems or replacement applications, this power cable is engineered and built from quality materials that meet current safety approvals to deliver and maintain reliable connections. Fully molded boots with strain relief, a durable PVC jacket, and heavy-duty construction enable this power cable to help provide maximum electrical conductivity to transmit dependable power where and when needed.
Specifications
| Ports & interfaces | |
|---|---|
| Connector 2 | IEC C13 |
| Connector 1 | CEE7/7 |
| Cable length | 5 m |
| Features | |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Conductor material | Copper |
| Number of conductors | 3 |
| Cable type | H05VV-F3G |
| Jacket material | Polyvinyl chloride (PVC) |
| Connector 2 | IEC C13 |
| Connector 1 | CEE7/7 |
| Cable length | 5 m |
| Conductor cross section | 0.75 mm² |
| Connector 2 standard | IEC 60320 |
| Connector 2 gender | Female |
| Connector 1 gender | Male |
| Product colour | Black |
| Package type | Polybag |
| Power | |
| Input voltage | 250 V |
| Input current | 2.5 A |
| Colour | |
| Product colour | Black |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 90% |
| Certificates | |
| Compliance certificates | CE, REACH, RoHS, UKCA, VDE |
| Weight & dimensions | |
| Width | 48 mm |
| Depth | 40 mm |
| Weight | 340 g |
| Diameter | 6.8 mm |
| Package width | 135 mm |
| Package depth | 40 mm |
| Package height | 240 mm |
| Package weight | 350 g |
| Packaging data | |
| Package type | Polybag |
| Package width | 135 mm |
| Package depth | 40 mm |
| Package height | 240 mm |
| Package weight | 350 g |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Jacket material | Polyvinyl chloride (PVC) |
| Conductor cross section | 0.75 mm² |
| Compliance certificates | CE, REACH, RoHS, UKCA, VDE |
| Logistics data | |
| Master (outer) case gross weight | 15 kg |
| Products per master (outer) case | 40 pc(s) |
| Master (outer) case width | 400 mm |
| Master (outer) case length | 300 mm |
| Master (outer) case height | 280 mm |
