Part No:AP6020A
Stock:22 In Stock
EAN Code:0731304327806
AP6020AFeatures
- Rack PDU, Basic, 0U/1U, 100-240V/20A, 220-240V/16A, (13) C13
- Reliable rack power distribution
- Includes : Installation guide , Safety guide
Marketing Features
Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Agility
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Total Cost of Ownership
Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Design | |
---|---|
Type | Single-phase |
PDU types | Basic |
Mounting | Horizontal/Vertical |
Product colour | Black |
Certification | cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH |
Rack capacity | 0U/1U |
Ports & interfaces | |
AC outlets quantity | 13 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C20 coupler |
Output connections | IEC 320 C13 |
Features | |
Certification | cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH |
Power | |
Maximum power | 3680 W |
Nominal input voltage | 100-240 V |
Maximum current | 20 A |
Maximum total current draw per phase | 16 A |
Maximum input current per phase | 16 A |
Load capacity | 3680 VA |
AC input frequency | 50 - 60 Hz |
Weight & dimensions | |
Dimensions (WxDxH) | 44 x 93 x 388 mm |
Weight | 1.5 kg |
Package weight | 2.02 kg |
Package dimensions (WxDxH) | 210 x 76 x 436 mm |
Packaging data | |
Package weight | 2.02 kg |
Package dimensions (WxDxH) | 210 x 76 x 436 mm |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -15 - 60 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 5 - 95% |
Operating altitude | 0 - 3048 m |
Technical details | |
Sustainability certificates | RoHS |
