EU Product - 48V Dc Indusril Power

Introduction

The POW-4851 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 70 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well.

Specifications

Design
Safety	IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3, EN61000-4-2/3/4/5/6/8/11, EN61000-6-2, EN61204, EN55024
Product colour	Blue, Silver
Country of origin	China
Power
Total power	240 W
AC input voltage	90 - 264 V
Power protection features	Over voltage, Overload, Short circuit
Performance
Safety	IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3, EN61000-4-2/3/4/5/6/8/11, EN61000-6-2, EN61204, EN55024
Mean time between failures (MTBF)	230200 h
Country of origin	China
Harmonized System (HS) code	84733020
Operational conditions
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 95%
Technical details
Technical features	48V DC Out
Weight & dimensions
Width	125.2 mm
Depth	113.5 mm
Height	63 mm
Weight	1 kg
Packaging data
Package depth	113.5 mm
Package width	125.2 mm
Package height	63 mm
Package weight	1 kg
Certificates
Safety	IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3, EN61000-4-2/3/4/5/6/8/11, EN61000-6-2, EN61204, EN55024
Logistics data
Harmonized System (HS) code	84733020
Other features
Maximum current	5 A
Technical features	48V DC Out
Harmonized System (HS) code	84733020
