NETSHELTER SX 18U SRVR RACK ENC
Introduction
APC NetShelter SX server rack enclosure with the most standard features for speed of deployment and installation. Rack design offers 18RU height with 921 mm max equipment mounting depth, 408 kg (900 lb) static load, and 408 kg (900 lb) dynamic load and two 0U accessory channels. Ready for low to medium density edge computing. Shorter height allows for deployment underneath cabinets, desks, in remote office branch office spaces for a secure and discrete solution for IT devices.
Specifications
| Features | |
|---|---|
| Size (imperial) | 48.3 cm (19") |
| Key lock | Yes |
| Frame type | Closed |
| Rack capacity | 18U |
| International Protection (IP) code | IP20 |
| Castor wheels | Yes |
| Adjustable mounting rails | Yes |
| Removable back door | Yes |
| Removable front door | Yes |
| Removable side panels | Yes |
| Back door construction | Perforated |
| Cable management | Yes |
| Adjustable feet | Yes |
| Side panel key lock | Yes |
| Type | Freestanding rack |
| Side panels included | Yes |
| Maximum weight capacity | 409 kg |
| Product colour | Black |
| Certification | REACH UL 2416, UL 60950-1 |
| Weight & dimensions | |
| Package depth | 1240 mm |
| Package width | 750 mm |
| Package height | 1220 mm |
| Package weight | 127 kg |
| Mounting depth (max) | 92.1 cm |
| Mounting depth (min) | 19.1 cm |
| Width | 600 mm |
| Depth | 1070 mm |
| Height | 925 mm |
| Weight | 72.1 kg |
| Size (imperial) | 48.3 cm (19") |
| Maximum weight capacity | 409 kg |
| Packaging data | |
| Package depth | 1240 mm |
| Package width | 750 mm |
| Package height | 1220 mm |
| Package weight | 127 kg |
| Technical details | |
| Package width | 750 mm |
| Package height | 1220 mm |
| Type | Freestanding rack |
| Size (imperial) | 48.3 cm (19") |
| Side panels included | Yes |
| Harmonized System (HS) code | 85381000 |
| Total carbon footprint (kg of CO2e) | 445.70309377248384 |
| Compliance certificates | RoHS, REACH, WEEE |
| Rack capacity | 18U |
| International Protection (IP) code | IP20 |
| Colour | |
| Product colour | Black |
| Certificates | |
| Certification | REACH UL 2416, UL 60950-1 |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Packaging content | |
| Side panels included | Yes |
| Certification | |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Logistics data | |
| Country of origin | China |
| Customs product code (TARIC) | 9403208000 |
| Harmonized System (HS) code | 85381000 |
