EU Product - Scanner Ads-1800 Dokumentenscanner - Document Scanners - A4
Introduction
Brother ADS-1800W. Maximum scan size: 215.9 x 355.6 mm, Optical scanning resolution: 1200 x 1200 DPI, ADF scan speed (b/w, A4): 20 ppm. Scanner type: ADF scanner, Product colour: White, Display: LCD. Scan to: FTP, PC, SMB, Scan drivers: SANE, TWAIN, WIA, Scanning noise level: 62 dB. Auto document feeder (ADF) input capacity: 20 sheets. Maximum ISO A-series paper size: A4, Scanning media types supported: Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper, ISO A-series sizes (A0...A9): A4
Specifications
| Scanning | |
|---|---|
| Maximum scan size | 215.9 x 355.6 mm |
| Optical scanning resolution | 1200 x 1200 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Greyscale levels | 256 |
| ADF scan speed (b/w, A4) | 20 ppm |
| Scan to | FTP, PC, SMB |
| Design | |
| Built-in display | Yes |
| Touchscreen | Yes |
| Scanner type | ADF scanner |
| Display diagonal | 7.11 cm (2.8") |
| Display | LCD |
| Product colour | White |
| Colour display | Yes |
| Control type | Buttons, Touch |
| Performance | |
| Scan to | FTP, PC, SMB |
| Scan drivers | SANE, TWAIN, WIA |
| Scanning noise level | 62 dB |
| Input capacity | |
| Auto document feeder (ADF) input capacity | 20 sheets |
| Paper handling | |
| Maximum ISO A-series paper size | A4 |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| ISO A-series sizes (A0...A9) | A4 |
| Card thickness (max) | 1.24 mm |
| Paper tray media weight | 51.8 - 128 g/m² |
| Ports & interfaces | |
| USB connector type | USB Type-C |
| USB port | Yes |
| USB version | 2.0 |
| Network | |
| Security algorithms | 64-bit WEP, 128-bit WEP, EAP-TLS, EAP-TTLS, SMTP-AUTH, SNMPv3, SSH, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPA3-PSK, WPA3-SAE |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| IPv6 support | Yes |
| Software | |
| Scan drivers | SANE, TWAIN, WIA |
| Sound emission | |
| Scanning noise level | 62 dB |
| Power | |
| Power consumption (typical) | 12 W |
| Power consumption (off) | 0.1 W |
| Power supply type | USB |
| Weight & dimensions | |
| Width | 158 mm |
| Depth | 200 mm |
| Height | 369 mm |
| Weight | 1.49 kg |
| Package weight | 2.41 kg |
| Packaging data | |
| Package weight | 2.41 kg |
| Products per pallet | 60 pc(s) |
| Packaging content | |
| Cables included | USB |
| Technical details | |
| Pallet gross height | 12.7 cm |
| Security algorithms | 64-bit WEP, 128-bit WEP, EAP-TLS, EAP-TTLS, SMTP-AUTH, SNMPv3, SSH, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPA3-PSK, WPA3-SAE |
| Scanner type | ADF scanner |
| Country of origin | China |
| Product colour | White |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
| Master (outer) cases per pallet layer | 4 pc(s) |
| Pallet type | 800 x 1200 mm |
| Display | |
| Touchscreen | Yes |
| Display diagonal | 7.11 cm (2.8") |
| Display | LCD |
| Media formats | |
| ISO A-series sizes (A0...A9) | A4 |
| Features | |
| Country of origin | China |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Other features | |
| Pallet gross weight | 162.4 kg |
| Security algorithms | 64-bit WEP, 128-bit WEP, EAP-TLS, EAP-TTLS, SMTP-AUTH, SNMPv3, SSH, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-TKIP, WPA3-PSK, WPA3-SAE |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Scanner type | ADF scanner |
| Country of origin | China |
| Products per pallet | 60 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
| Logistics data | |
| Pallet gross weight | 162.4 kg |
| Country of origin | China |
| Products per pallet | 60 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
| Pallet gross height | 12.7 cm |
| Master (outer) cases per pallet layer | 4 pc(s) |
