Specifications

Technical details
Maximum number of doors	4 door(s)
Case design	Bare
Built-in UPS	No
Interface	RS-485
Supported network protocols	IPv4; TCP; UDP
Number of Wiegand readers supported	4
Number of users	100000 user(s)
Exit button supported	Yes
Performance
Number of Wiegand readers supported	4
Certification	CE/FCC/UL
Wiegand interface	Yes
Alarm input channels	1
Active tampering alarm	Yes
Power
Power consumption (typical)	41.6 W
Operating voltage	12 V
Operating current	1.4 A
Power consumption (no load)	0.8 W
Ports & interfaces
RS-485 ports	5
Operational conditions
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	5 - 90%
Weight & dimensions
Width	210 mm
Height	106 mm
Depth	50 mm
Packaging data
Package width	255 mm
Package height	166 mm
Package depth	87 mm
Package weight	600 g
