Specifications

Performance
Channels quantity	1 channels
Alarm input channels	4
Alarm output channels	4
Maximum video resolution	3840 x 2160 pixels
Maximum frame rate	30 fps
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3860 x 2160
Video formats supported	H.264, H.265, H.265+, M-JPEG, MPEG2, MPEG4
Audio formats supported	G.711, PCM
Features
Product colour	Black
Network
Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Ports & interfaces
Number of HDMI outputs	1
VGA (D-Sub) output ports	1
Ethernet LAN (RJ-45) ports	1
RS-232 ports	1
RS-485 ports	1
Power
AC adapter output voltage	12 V
AC adapter output current	3.3 A
Power consumption (min)	20 W
Operational conditions
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	440 mm
Depth	322.8 mm
Height	44 mm
Weight	3.2 kg
