Specifications
| Performance | |
|---|---|
| Video input channels | 16 channels |
| Alarm input channels | 4 |
| Alarm output channels | 2 |
| Video codecs | H.264/.H265/Smart H.264+/Smart H.265+/MJPEG |
| Supported network protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS |
| Backup function | Yes |
| Audio codecs | PCM/G711A/G711U/G26/AAC |
| Built-in processor | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Video motion detection | Yes |
| Operating system installed | Embedded LINUX |
| Wireless LAN features | |
| Wi-Fi | No |
| Hard drive | |
| Number of HDDs supported | 2 |
| Maximum storage capacity | 10 TB |
| HDD interface | SATA |
| Storage | |
| Number of HDDs supported | 2 |
| Maximum storage capacity | 10 TB |
| HDD interface | SATA |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power over Ethernet (PoE) | Yes |
| VGA (D-Sub) output ports | 1 |
| HDMI output | Yes |
| USB 2.0 ports quantity | 2 |
| Supported network protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS |
| Audio RCA inputs | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Audio RCA outputs | 1 |
| Power over Ethernet (PoE) ports quantity | 16 |
| HDMI ports quantity | 1 |
| Storage relative humidity (H-H) | 30 - 85% |
| Features | |
| Rack mounting | Yes |
| Certification | FCC:47 CFR FCC Part15,SubpartB,Class A CE-EMC:EN 55032:2015,Class A;EN IEC 61000- 3-2:2019;EN 61000-3-3:2013+A1:2019;EN 55024:2010+A1:2015;EN 55035:2017;EN 50130- 4:2011+A1:2014 CE-LVD:EN 62368-1:2014+A11:2017 |
| Rack capacity | 1U |
| Product colour | Black |
| Processor | |
| Built-in processor | Yes |
| Power | |
| Power consumption (typical) | 10 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Total Power over Ethernet (PoE) budget | 130 W |
| Power over Ethernet (PoE) power per port | 25.5 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 93% |
| Storage temperature (T-T) | -10 - 55 °C |
| Storage relative humidity (H-H) | 30 - 85% |
| Weight & dimensions | |
| Width | 375 mm |
| Depth | 329.3 mm |
| Height | 53 mm |
| Weight | 2.63 kg |
| Package width | 148 mm |
| Package depth | 449 mm |
| Package height | 421 mm |
| Package weight | 3.91 kg |
