| Performance |
|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Certification | CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB ) |
| Thermal sensitivity (NETD) | 40 mK |
| Thermal module | Yes |
| Design |
|---|
| Form factor | Bullet |
| Product colour | Black, White |
| Mounting type | Wall |
| International Protection (IP) code | IP67 |
| Housing material | Metal |
| Camera |
|---|
| Camera pixel size | 17 µm |
| Lens viewing angle, horizontal | 11.1° |
| Lens viewing angle, vertical | 8.3° |
| Image sensor |
|---|
| Sensor type (thermal module) | Vanadium Oxide Uncooled Focal Plane Arrays |
| Effective sensor resolution (thermal module) | 400 x 300 pixels |
| Lens system |
|---|
| Number of lenses | 1 |
| Digital zoom | 4x |
| Focal length range | 7.5 - 35 mm |
| Fixed focal length | 1 mm |
| Video |
|---|
| Flip & mirror | Yes |
| Region of Interest (ROI) encoding | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Bit rate | 640 ~ 8192 |
| Video compression formats | H.264, H.265 |
| Video formats supported | H.264, H.265 |
| Supported graphics resolutions | 400 x 300, 640 x 512, 1280 x 1024 (SXGA) |
| Supported video modes | 720p |
| Frame rate | 30 fps |
| Audio |
|---|
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio formats supported | AAC, G.711 A-law, G.711 µ-law, PCM |
| Network |
|---|
| Bluetooth | No |
| Number of users | 20 user(s) |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
| Storage |
|---|
| Maximum memory card size | 256 GB |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash) |
| Ports & interfaces |
|---|
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| Intelligent Video Surveillance (IVS) system features | Intrusion, Tripwire |
| Video motion detection | Yes |
| Mirror | Yes |
| Human and vehicle targets classification | Yes |
| Alarm input channels | 2 |
| Alarm output channels | 2 |
| Fire detection | Yes |
| Power |
|---|
| Power source type | DC, PoE |
| Power consumption (max) | 13 W |
| DC output voltage | 12 |
| Certificates |
|---|
| Certification | CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB ) |
| Operational conditions |
|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 103 mm |
| Depth | 291 mm |
| Height | 97 mm |
| Weight | 1.5 kg |
| Package weight | 1.9 kg |
| Packaging data |
|---|
| Package weight | 1.9 kg |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.265 |
