EU Product - TM P20II 101 Dot-matrix - POS printer - Thermal Transfer
Introduction
2-inch portable receipt printer
Sporting an all-new, ultra-light and stylish design, this popular receipt printer offers a range of new and advanced features, as well as enhanced durability. Providing outstanding flexibility, reliability, connectivity and ease-of-use, it's perfect for busy, on-the-go environments such as retail, hospitality and in-vehicle applications.
Compact, stylish and ultra-light
Whatever your application, from retail to hospitality, this receipt printer is designed to make life easy. Wi-Fi model weighing only 223g (approx.) and Bluetooth model 216g (approx.), its ultra-light form factor makes it the ideal solution for any on-the-go environment.
Robust and reliable
When you’re out and about, your devices are exposed to many hazards of everyday life. But with its increased impact resistance and protection to IP54 standards, the TM-P20II is designed to withstand most ordinary knocks, as well as exposure to dust and water.
Outstanding connectivity, range and battery life
With USB-C connectivity, plus support for Bluetooth 5.0 “classic” and low-energy modes, it provides excellent range, seamless pairing and reliable all-day battery life, while its Wi-Fi 5 capability means that it offers excellent wireless performance, including a Wi-Fi “Direct” mode enabling direct connection of up to 8 devices without the need to connect to a network or hotspot.
Great for in-vehicle applications
Fully approved for use in vehicles, the highly compact and fully self-contained TM-P20II is easily integrated into your workflow, helping you to become more efficient and productive.
Easy and comfortable to carry
Super-light and ergonomically designed, the TM-P20II can be easily mounted onto a belt, or shoulder carried using an (optional) strap.
Fast, easy set-up
Because the TM-P20II comes with a comprehensive “quick start” sheet, which includes QR-codes that link to video guides, set-up and configuration is simple and hassle-free - so you can be up and running almost instantly.
Specifications
| Printing | |
|---|---|
| Colour | No |
| Type | Mobile printer |
| Print technology | Thermal |
| Print speed | 100 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Performance | |
| Type | Mobile printer |
| Print technology | Thermal |
| Print speed | 100 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Paper handling | |
| Printing media thickness | 75 µm |
| Maximum printing width | 5.8 cm |
| Paper loading type | Top & front |
| Ports & interfaces | |
| Interface | Bluetooth, USB Type-C |
| Connectivity technology | Wired & Wireless |
| Bluetooth version | 5.0 |
| Bluetooth | Yes |
| USB port | Yes |
| USB connector | USB Type-C |
| Print technology | |
| Type | Mobile printer |
| Print technology | Thermal |
| Print speed | 100 mm/sec |
| Print quality | |
| Maximum resolution | 203 x 203 DPI |
| Maximum printing width | 5.8 cm |
| Technical details | |
| Interface | Bluetooth, USB Type-C |
| Maximum printing width | 5.8 cm |
| Product colour | Black |
| Products per pallet | 288 pc(s) |
| Cutter | Yes |
| Quantity per pack | 1 pc(s) |
| Country of origin | Philippines |
| Products per pallet layer (UK) | 48 pc(s) |
| Products per pallet layer | 32 pc(s) |
| Products per pallet (UK) | 432 pc(s) |
| Technology | Thermal Line |
| Colour | No |
| Box contents | Battery (OT-BY20), Belt clip, Main unit, Quick Start Guide, Roll paper, Setup guide, USB cable, Warranty document |
| Print speed | Max. 100 mm/sec at 203 x 203 DPI ( printing width58 mm) |
| Features | |
| Product colour | Black |
| Sound pressure level (printing) | 53 dB |
| Cutter | Yes |
| Country of origin | Philippines |
| Design | |
| Product colour | Black |
| Power | |
| AC input voltage | 7.2 V |
| Power source type | DC |
| Battery capacity | 1240 mAh |
| Operational conditions | |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 79 mm |
| Depth | 120 mm |
| Height | 46 mm |
| Package width | 220 mm |
| Package depth | 162 mm |
| Package height | 95 mm |
| Package weight | 596 g |
| Weight | 220 g |
| Packaging data | |
| Package width | 220 mm |
| Package depth | 162 mm |
| Package height | 95 mm |
| Package weight | 596 g |
| Cables included | USB |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Cables included | USB |
| Quantity per pack | 1 pc(s) |
| Battery | |
| Battery capacity | 1240 mAh |
| Logistics data | |
| Products per pallet | 288 pc(s) |
| Products per pallet layer (UK) | 48 pc(s) |
| Products per pallet layer | 32 pc(s) |
| Products per pallet (UK) | 432 pc(s) |
