Network Ceiling Loudspeaker CS10
Introduction
The Yealink CS10, a low-profile (120mm) 2-way coaxial network speaker, excels in video conferencing with its exceptional audio performance. Designed specifically for the modern meeting environment, the CS10 blends high-quality audio with an elegant, minimalist design, making it a perfect match for contemporary conference rooms. Versatile and engineered for ease of use, the CS10 is a PoE-enabled speaker that can optionally deployed with variety supplementary components, simplifying installation across diverse ceiling types. Its covert design, establishes the CS10 as more than just a speaker – it is an essential addition to your meeting space, enhancing both visual and auditory experiences.
Specifications
| Features | |
|---|---|
| Product type | Speaker |
| Product colour | White, Black |
| Audio | |
| Frequency range | 100 - 20000 Hz |
| Impedance | 8 O |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power source type | PoE |
| Weight & dimensions | |
| Width | 294 mm |
| Depth | 294 mm |
| Height | 125.8 mm |
| Weight | 2.31 kg |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | 0 - 50 °C |
| Logistics data | |
| Country of origin | China |
| Packaging data | |
| Package width | 398 mm |
| Package depth | 355 mm |
| Package height | 185 mm |
| Package weight | 4.63 kg |
| Packaging content | |
| Quantity | 1 |
| Packaging content | White Mesh Cover (Black Optional), Quick Start Guide, Assembly Fixing Bracket, Dust Cover, Deployment Instruction Templete, Bracing Bridge, Dust Cover Screw*6 (M3*4CMHOZN3) |
