STARTECH.COM TB3DKM2DPL STARTECH.COM THUNDERBOLT 3 MINI DOCK

*Image accuracy is not guaranteed. Please do not rely on the image for your purchase.. ** All heavy items above 25KG will be charged shipping cost as per actual. Please contact us for a shipping quote before placing order

TB3DKM2DPL STARTECH.COM THUNDERBOLT 3 MINI DOCK

Part No:TB3DKM2DPL

Stock:12 In Stock

EAN Code:0065030888059

£87.15 Excl. VAT

£104.58 Incl. VAT

price matchPrice Match
Guarantee
Delivery1-2 days delivery
customer satisfaction100% Customer
Satisfaction
secure paymentSecure Payment
Options
Accept Purchase orders
We accept Purchase Orders from Education Sector, Hospitals, Police, Councils and more.Choose Payment Option "Purchase Order" While placing your order online.

Any Questions?

If you have any questions about price and availability of the product, please drop us a query below:

THUNDERBOLT 3 MINI DOCK

Introduction

Laptop Docking Station | Mac & Windows® | Bus-Powered | 1x USB-AThis certified Thunderbolt™ 3 docking station is a compact mini dock, delivering essential connections for productivity. The bus-powered dock connects dual 4K DisplayPort displays, Gigabit Ethernet, and one USB-A (USB 3.2) port and for flexible set up, the attached Thunderbolt 3 cable has an extended length of (11 in./ 28 cm).Create a Dual-4K 60Hz WorkstationGreat for editing 4K video or other Ultra HD tasks, this portable Thunderbolt™ 3 to DisplayPort dock supports 40 Gbps of throughput and 4K resolution at 60Hz on dual DisplayPort monitors, through a single Thunderbolt™ 3 port. Run resource-demanding applications on two independent displays without draining system resources.Connect your laptop to:• 2x 4K DisplayPort (DP) displays (up to 4096 x 2160p @ 60Hz)Compact Size & 11-Inch Attached Host CableAt just 2.4" x 4.9" (6.1 cm x 12.4 cm), this dock takes up minimal room on your desk and in your laptop case. The dock's 28 cm (11 inches) attached cable provides extended reach to reduce port/connector strain on MacBooks and laptops on riser stands, or if needed, offers the flexibility to position dock further away from the laptop on your desk.The Ports You Need Most• 1x USB 3.2 Gen 1 Type-A port (5 Gbps)• 1x Gigabit Ethernet port (with PXE Boot and Wake-on-LAN support)Ideal for Power-Demanding Workstation SetupsAs many high powered, later generation laptops optimally require more than 100W of power to stay charged, some users prefer to use their laptop's power adapter vs. using their docking stations to keep laptops charged.This bus-powered TB3 mini dock is ideally suited for those users, providing full Thunderbolt™ 3 docking station performance and functionality, while their workstation laptops are separately charged."The TB3DKM2DPL is Thunderbolt Certified and backed by a StarTech.com 3-year warranty and free lifetime technical support.The StarTech.com Advantage

Specifications

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Host interfaceThunderbolt 3
Ethernet LAN (RJ-45) ports1
DisplayPorts quantity2
Microphone inNo
Connectivity technologyWired
Network
Networking standardsIEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Wake-on-LAN readyYes
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports1
Performance
Maximum digital resolution3840 x 2160 pixels
Number of displays supported2
Product colourGrey
Card reader integratedNo
Data transfer rate5 Gbit/s
Housing materialAluminium, Plastic
Technical details
Product colourGrey
Data transfer rate5 Gbit/s
Cable length0.28 m
Sustainability certificatesCE, RoHS
Harmonized System (HS) code84733020
Products per master (outer) case24 pc(s)
Master (outer) case width300 mm
Master (outer) case length437 mm
Master (outer) case height270 mm
Storage
Card reader integratedNo
Software
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supportedWindows Server 2008 R2, Windows Server 2012, Windows Server 2012 x64
Operational conditions
Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 95%
Sustainability
Sustainability certificatesCE, RoHS
Weight & dimensions
Weight147.8 g
Width69 mm
Depth124 mm
Height27 mm
Package weight270 g
Package width139 mm
Package depth195 mm
Package height37 mm
Design
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Product colourGrey
Packaging data
Package weight270 g
Package width139 mm
Package depth195 mm
Package height37 mm
Packaging content
ManualYes
Logistics data
Products per master (outer) case24 pc(s)
Master (outer) case width300 mm
Master (outer) case length437 mm
Master (outer) case height270 mm
Harmonized System (HS) code84733020
Other features
ChipsetIntel JHL6540 (Alpine Ridge), Texas Instruments TPS65983A, Parade PS176, ASMedia ASM1042A, Intel WGI210
Cable length0.28 m
