Part No:PEXUSB312A1C1H
Stock:10 In Stock
EAN Code:0065030888325
2x USB 3.2 Gen 2x1 (10Gbps) Type-A | 1x USB 3.2 Gen 2x1 (10Gbps) Type-C 2x1 | 2x USB 3.2 Gen 1x1 (5Gbps) IDCThe StarTech.com Advantage
Ports & interfaces | |
---|---|
Internal | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Output interface | USB 3.2 Gen 2 (3.1 Gen 2) |
Internal SATA ports quantity | 1 |
Host interface | PCIe |
Expansion card standard | PCIe 3.0 |
Technical details | |
Chipset | ASMedia - ASM3142, Genesys Logic - GL3590 |
Data transfer rate (max) | 10 Gbit/s |
Sustainability certificates | CE, RoHS |
Performance | |
UASP support | Yes |
Chipset | ASMedia - ASM3142, Genesys Logic - GL3590 |
Data transfer rate (max) | 10 Gbit/s |
Product colour | Red |
Harmonized System (HS) code | 84733020 |
Colour | |
Product colour | Red |
Design | |
Mean time between failures (MTBF) | 1677495 h |
Internal | Yes |
Product colour | Red |
Features | |
UASP support | Yes |
Chipset | ASMedia - ASM3142, Genesys Logic - GL3590 |
Data transfer rate (max) | 10 Gbit/s |
Harmonized System (HS) code | 84733020 |
Operational conditions | |
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -20 - 80 °C |
Operating relative humidity (H-H) | 15 - 90% |
System requirements | |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2019 |
Weight & dimensions | |
Width | 68.9 mm |
Depth | 102 mm |
Height | 14.4 mm |
Weight | 60 g |
Package width | 140 mm |
Package depth | 175 mm |
Package height | 30 mm |
Package weight | 125 g |
Packaging data | |
Mounting brackets included | Yes |
Package width | 140 mm |
Package depth | 175 mm |
Package height | 30 mm |
Package weight | 125 g |
Quick installation guide | Yes |
Logistics data | |
Products per master (outer) case | 60 pc(s) |
Master (outer) case width | 370 mm |
Master (outer) case length | 375 mm |
Master (outer) case height | 500 mm |
Harmonized System (HS) code | 84733020 |
Packaging content | |
Mounting brackets included | Yes |
Quick installation guide | Yes |
Other features | |
Chipset | ASMedia - ASM3142, Genesys Logic - GL3590 |
