Part No:90AR0072-M00160
Stock:17 In Stock
EAN Code:4711387491744
Compact Power, Intelligent Performance
Smaller, Faster, Better, AI Ready
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.
Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifes pan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.
With a focus on supporting diverse businesses and enhancing PC applications, the ASUS NUC aspires to deliver on the brand promise of delivering the Next Unit of Compute (NUC) and make a lasting impact in the ever-evolving tech landscape.
Toolless Design
ASUS NUC 14 Pro offers toolless access to make it easy to open up the chassis to assess the M.2 PCIe SSD module for easy upgrades.
Certified Bluetooth
dongle-free experience
A certified Bluetooth dongle offers hassle-free operation, cost savings, and resolves ITDM issues. It eliminates concerns such as lost dongles, PC Bluetooth compatibility, and USB port limitations on NUC.
The dongle-free approach simplifies pairing, enhances audio quality, and improves control in video collaboration calls.
Motherboard | |
---|---|
Number of processors supported | 1 |
Processor | |
Thermal Design Power (TDP) | 28 W |
Built-in processor | Yes |
Processor model | 135H |
Processor threads | 18 |
Processor cores | 14 |
Processor family | Intel Core Ultra 5 |
Number of processors supported | 1 |
Processor manufacturer | Intel |
Processor cache | 18 MB |
Performance cores | 4 |
Efficient cores | 8 |
Performance-core boost frequency | 4.6 GHz |
Efficient-core boost frequency | 3.6 GHz |
Low Power Efficient-cores | 2 |
Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
Processor generation | Intel Core Ultra (Series 1) |
Memory | |
Memory slots type | SO-DIMM |
Number of memory slots | 2 |
Memory channels | Dual-channel |
Supported memory types | DDR5-SDRAM |
Supported memory clock speeds | 5600 MHz |
Maximum internal memory | 96 GB |
Video | |
On-board graphics card | Yes |
Graphics card family | Intel |
Storage | |
Supported storage drive types | SSD |
Storage drive sizes supported | 2.5,M.2 |
Storage drive interface | PCI Express, Serial ATA III |
NVMe | Yes |
Graphics | |
On-board graphics card | Yes |
Graphics card family | Intel |
On-board graphics card model | Intel Graphics |
Audio | |
Built-in speaker(s) | No |
Network | |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
Bluetooth version | 5.3 |
Bluetooth | Yes |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
WLAN controller model | Intel Wi-Fi 6E AX211 |
Ports & interfaces | |
DC-in jack | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
HDMI version | 2.1 |
USB 2.0 ports quantity | 1 |
HDMI ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Thunderbolt 4 ports quantity | 2 |
USB4 Gen 2x2 ports quantity | 1 |
Design | |
VESA mounting | Yes |
Product type | Mini PC barebone |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Cooling type | Active |
Product colour | Black |
Chassis type | UCFF |
Performance | |
Windows operating systems supported | Windows 11 |
Number of processors supported | 1 |
Processor special features | |
Low Power Efficient-cores | 2 |
Low Power Efficient-core Max Turbo Frequency | 2.5 GHz |
Colour | |
Product colour | Black |
Technical details | |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Quick start guide | Yes |
Processor cores | 14 |
Cooling type | Active |
Chassis type | UCFF |
Packaging data | |
Power cord included | Yes |
Software | |
Windows operating systems supported | Windows 11 |
Power | |
Power supply type | External AC adapter |
Power supply | 120 W |
Weight & dimensions | |
Width | 144 mm |
Depth | 112 mm |
Height | 41 mm |
Weight | 570 g |
Packaging content | |
Power cord included | Yes |
Quick start guide | Yes |
Other features | |
Chassis type | UCFF |
