Part No:9PA1806203
Stock:4 In Stock
EAN Code:4713224523663
Cooling | |
---|---|
Fan diameter | 4 cm |
Number of fans | 1 fan(s) |
Cooling type | Active |
Design | |
80 PLUS certification | 80 PLUS |
Certification | CE, UL, cUL, FCC, TÜV, CCC ROHS |
Fan diameter | 4 cm |
Number of fans | 1 fan(s) |
Cooling type | Active |
Power | |
Total power | 180 W |
AC input voltage | 115 - 230 V |
AC input frequency | 47 - 63 Hz |
Power Factor Correction (PFC) type | Active |
Max output current (+3.3V) | 8 A |
Max output current (+12V) | 12 A |
Max output current (+5V) | 12 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2 A |
Power protection features | Over voltage, Overload, Short circuit |
Hold time | 16 ms |
Ports & interfaces | |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 1 |
Peripheral (Molex) power connectors (4-pin) | 2 |
Floppy disk drive connector | Yes |
Performance | |
Power supply unit (PSU) form factor | Flex ATX |
80 PLUS certification | 80 PLUS |
Purpose | PC/Server |
Mean time between failures (MTBF) | 100000 h |
Certification | CE, UL, cUL, FCC, TÜV, CCC ROHS |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -20 - 80 °C |
Weight & dimensions | |
Width | 150 mm |
Depth | 40.5 mm |
Height | 81.5 mm |
Technical details | |
Compliance certificates | RoHS |
Certificates | |
80 PLUS certification | 80 PLUS |
Certification | CE, UL, cUL, FCC, TÜV, CCC ROHS |
