Introduction
The Lindy 4K60 HDMI® over IP Encoder is designed to stream AV content over IP networks using the H.265 or H.264 video compression standard,it supports resolutions up to 3840x2160@60Hz 4:4:4 8bit with a HDMI® loop out port for a local display.
Support RTSP/UDP, RTSP/TCP, RTP/UDP, TS/UDP, RTMP/RTMPS and SRT stream standards for the most popular services such as YouTube, Facebook Live, Twitch or custom-specified servers.
Mainstream and substreams can be configured with bit rates, simultaneous streaming and audio-only streaming is also supported.
This extender provides status LEDs and OLED display to show the IP address and have access to menu features, a web gui for the complete configuration and API commands to achieve flexible configurations including from third party control systems.
In addition the 1G Network port has PoE function to power the unit without a PSU.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Specifications
| Video | |
|---|---|
| Video compression formats | H.264, H.265 |
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 60 fps |
| Design | |
| LED indicators | Yes |
| Product colour | Black |
| Housing material | Metal |
| Network | |
| Power over Ethernet (PoE) | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Audio connector type | 3.5 mm (1/8") |
| HDMI input ports quantity | 1 |
| Power | |
| Input voltage | 12 V |
| Weight & dimensions | |
| Weight | 190 g |
| Width | 160 mm |
| Depth | 130 mm |
| Height | 30 mm |
| Packaging data | |
| Package weight | 1.02 kg |
| Package width | 213 mm |
| Package depth | 181 mm |
| Package height | 77 mm |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Sustainability | |
| Compliance certificates | CE, UKCA, REACH, RoHS, Federal Communications Commission (FCC) |
| Technical details | |
| Package weight | 1.02 kg |
| Product colour | Black |
| Housing material | Metal |
| Compliance certificates | CE, UKCA, REACH, RoHS, Federal Communications Commission (FCC) |
| Indication | |
| LED indicators | Yes |
