EU Product - CAT8.1 40G Keystone-Modul STP und werkzeuglos
Introduction
Cat8.1 STP 40G Shielded Keystone Jack for easy, fast and tool-free deployment in data centers
The Cat8.1 40G Shielded Toolless Keystone Jack from Intellinet Network Solutions is designed for quick, seamless deployment, especially for Top of Rack (ToR) and Middle of Row (MoR) installations in data centers. Without any special tools, this module easily snaps into blank patch panels, wall plates or surface connection boxes.
Future-proof high-end connection
This keystone jack is suitable for both stranded and solid conductor cables for ultra-high performance network applications up to 25GBase-T and 40GBase-T with PoE applications up to IEEE802.3bt / PoE++ / 4PPoE / Ultra PoE. For maximum signal integrity, it is equipped with gold-plated contacts and 360° STP shielding.
Specifications
| Features | |
|---|---|
| Construction type | Flat |
| Product colour | Silver |
| Connector 1 | RJ-45 |
| Connector 1 gender | Female |
| Connector contacts plating | Gold |
| Cable types supported | Cat8.1 |
| Certification | CE RoHS FCC ISO/IEC 11801 IEC 60603-7-51 |
| Cable shielding | U/FTP (STP) |
| Frequency | 2000 MHz |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Harmonized System (HS) code | 85369010 |
| Weight & dimensions | |
| Width | 16.2 mm |
| Depth | 30.1 mm |
| Height | 22.9 mm |
| Weight | 20 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 85369010 |
