EU Product - C.6 Wll Oule 2xRJ45 SP
Introduction
LogiLink’s Cat.6 shielded, angled, with zinc die casting housing wall outlet is ready for the transmission of digital and analogue voice, data and video up to 1 Gigabit Ethernet. The high-grade outlet is suitable for all current and future applications in Cat.5e and Cat.6 systems up to 1GbE. This wall outlet is also suitable for Power over Ethernet (PoE). Together with optional back box, this face plate becomes a Cat.6 surface mount box outlet.
Specifications
| Performance | |
|---|---|
| Sockets quantity | 2 |
| Socket type | RJ-45 |
| Networking cable category | 6 |
| Certification | ISO/IEC 11801, TIA/EIA 568B.2-1 |
| Cable type | STP |
| Features | |
| Sockets quantity | 2 |
| Socket type | RJ-45 |
| Networking cable category | 6 |
| Cable type | STP |
| Design | |
| Frame | Yes |
| Product colour | Metallic, White |
| Certification | ISO/IEC 11801, TIA/EIA 568B.2-1 |
| Technical details | |
| Harmonized System (HS) code | 85366990 |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 80 mm |
| Depth | 80 mm |
| Height | 38.8 mm |
| Packaging data | |
| Package width | 80 mm |
| Package depth | 80 mm |
| Package height | 40 mm |
| Package weight | 250 g |
| Logistics data | |
| Harmonized System (HS) code | 85366990 |
