EU Product - Geh MINI Classic BD-25B-350GPB (B) USB3.0
Introduction
BD-25B-350GPB
The Chieftec CLASSIC Series brings new life to the proven quality and the decade-old success of the UNI Series with a refreshed front panel design on the outside, while upgrading the quality and features on the inside. Built from 0.7 mm sturdy SECC and including toolless drive installation kits, the CLASSIC series is perfect for system builders who value true quality and timeless design.
Specifications
| Design | |
|---|---|
| Material thickness | 0.7 mm |
| Number of external 5.25" bays | 2 |
| Material | SECC |
| Number of 5.25" bays | 2 |
| Number of 3.5" bays | 3 |
| Number of 2.5" bays | 1 |
| Number of internal 3.5" bays | 2 |
| Supported motherboard form factors | Mini-ATX, Mini-ITX |
| Side window | No |
| Product colour | Black |
| Number of expansion slots | 7 |
| Maximum CPU cooler height | 14 cm |
| Maximum graphics card length | 34 cm |
| Type | PC |
| Technical details | |
| Number of 5.25" bays | 2 |
| Number of 3.5" bays | 3 |
| Number of 2.5" bays | 1 |
| Number of internal 3.5" bays | 2 |
| Supported motherboard form factors | Mini-ATX, Mini-ITX |
| Supported HDD sizes | 2.5,3.5,5.25" |
| Side window | No |
| Product colour | Black |
| Number of expansion slots | 7 |
| Maximum CPU cooler height | 14 cm |
| Maximum graphics card length | 34 cm |
| Type | PC |
| Harmonized System (HS) code | 84733080 |
| Material | |
| Material | SECC |
| Material thickness | 0.7 mm |
| Power supply | |
| Power supply included | Yes |
| Power supply | 350 W |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Audio input | Yes |
| Audio output | Yes |
| Cooling | |
| Number of front fans supported (max) | 1 |
| Front fans diameters supported | 80,90 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 80,90,120 mm |
| Storage | |
| Supported HDD sizes | 2.5,3.5,5.25" |
| Packaging content | |
| Screws included | Yes |
| Weight & dimensions | |
| Width | 198 mm |
| Depth | 375 mm |
| Height | 370 mm |
| Weight | 5.5 kg |
| Material thickness | 0.7 mm |
| Packaging data | |
| Package weight | 6.5 kg |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Other features | |
| Harmonized System (HS) code | 84733080 |
| Screws included | Yes |
