Specifications
| Ports & interfaces | |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| Host interface | USB Type-C |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Microphone in | No |
| Headphone outputs | 0 |
| Connectivity technology | Wired |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| Network | |
| Networking standards | IEEE 802.3ab |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Copper ethernet cabling technology | 1000BASE-T |
| Performance | |
| Country of origin | China |
| Product colour | Black, Grey |
| Card reader integrated | Yes |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| HD type | 4K Ultra HD |
| Housing material | Aluminium |
| Technical details | |
| Product colour | Black, Grey |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Harmonized System (HS) code | 8471800000 |
| Compliance certificates | CE, REACH, RoHS |
| Products per master (outer) case | 100 pc(s) |
| Master (outer) case width | 460 mm |
| Master (outer) case gross weight | 9.3 kg |
| Master (outer) case length | 395 mm |
| Master (outer) case height | 220 mm |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Power | |
| USB cable length | 0.25 m |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Weight & dimensions | |
| Weight | 60 g |
| Width | 32.3 mm |
| Depth | 14.2 mm |
| Height | 153.5 mm |
| Package weight | 85 g |
| Package width | 198 mm |
| Package depth | 23 mm |
| Package height | 75 mm |
| Design | |
| Country of origin | China |
| Product colour | Black, Grey |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package weight | 85 g |
| Package width | 198 mm |
| Package depth | 23 mm |
| Package height | 75 mm |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Products per master (outer) case | 100 pc(s) |
| Master (outer) case width | 460 mm |
| Master (outer) case gross weight | 9.3 kg |
| Master (outer) case length | 395 mm |
| Master (outer) case height | 220 mm |
| Harmonized System (HS) code | 8471800000 |
