EU Product - mini DisplayPort auf HDMI aktiv - Adapter - Digital/Display/Video
Introduction
The Club 3D CAC-1170 is an active HDMI™ signal converter. The Mini DisplayPort™ 1.2 to HDMI™ 2.0 UHD Adapter is the easiest solution for connecting your Mini DisplayPort™ 1.2 enabled source device to an HDMI™ 2.0 enabled 4K UHD Television, monitor or Projector.
The adapter is fully compliant to HDMI™ 2.0 specification allowing for 6Gbps TMDS throughput per channel. The interface in the adapter has three lanes for HDMI data, clock, HPD signal and power, offering a total TMDS throughput of 18Gbps.
Supports up to 4K UHD Resolution at 60Hz.
The Mini DisplayPort™ 1.2 to HDMI™ 2.0 adapter supports (U)HD resolutions of up to 4K UHD 3840x 2160p @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video or gameplay. Use the adapter to play games, view video or browse the internet from your Mini DisplayPort™ 1.2 enabled device in (Ultra) high- resolution. Supporting up to 8 channels of audio, the adapter provides high-definition digital audio and video.
Specifications
| Ports & interfaces | |
|---|---|
| Connector contacts plating | Gold |
| Connector 2 | HDMI 2.0 |
| Connector 1 | Mini DisplayPort 1.2 |
| Cable length | 0.15 m |
| Technical details | |
| USB required | No |
| Product colour | Black |
| Cable length | 0.15 m |
| Country of origin | China |
| Compatible products | Supports AMD GCN cards, Nvidia® Maxwell cards and Intel® 4th Generation Integrated Graphics series and newer. Not intended for older graphics architectures. |
| Detachable antenna(s) | No |
| Colour | Yes |
| Applicability | Universal |
| Cable colour | Black |
| Compliance certificates | RoHS |
| Design | |
| Product colour | Black |
| Cable length | 0.15 m |
| Performance | |
| Converter type | Active |
| Country of origin | China |
| Maximum resolution (HDMI) | 3840 x 2160 pixels |
| Compatible products | Supports AMD GCN cards, Nvidia® Maxwell cards and Intel® 4th Generation Integrated Graphics series and newer. Not intended for older graphics architectures. |
| USB required | No |
| Compatible operating systems | Windows and Mac OS |
| Product colour | Black |
| Data transfer rate | 18 Gbit/s |
| System requirements | |
| Compatible operating systems | Windows and Mac OS |
| Weight & dimensions | |
| Width | 23 mm |
| Weight | 56 g |
| Depth | 10, 150 |
| Packaging data | |
| Package width | 60 mm |
| Package height | 182 mm |
| Package depth | 35 mm |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Country of origin | China |
| Colour | Yes |
| Cable colour | Black |
