EU Product - Adapter DisplayPort Mini 1.2> HDMI 2.0* - Adapter - Digital/Display/Video
Introduction
CAC-2170 - The Club 3Dis an active HDMI™ 2.0 signal converter. The Mini DisplayPort™ 1.2 to HDMI™ 2.0 UHD Active Adapter is the easiest solution for connecting your Mini DisplayPort™ 1.2 Game PC or Laptop to an HDMI™ enabled 4K UHD Television, monitor or Projector. The adapter is compliant to HDMI™2.0 specification allowing for 6Gbps TMD Sthroughput per channel. The interface in the adapter has three lanes for HDMI™ data, clock, HPD signal and power, offering a total TMDS throughput of 18Gbps.
Supports up to 4K UHD Resolution at 60Hz.
The Mini DisplayPort™ 1.2 to HDMI™ 2.0 UHD Active Adapter supports UHD resolutions of up to 4K UHD 4096x 2160p @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video or gameplay. Use the adapter to play games, view video or browse the internet from your MiniDisplayPort™ 1.2 enabled device in Ultra High Resolution. Supporting up to 8 channels of audio, the adapter provides Ultra High Definition digital audio and video. It is the ideal solution for anyone who wants to enjoy 4K UHD/ 60 gameplay but lacks a native HDMI™ 2.0 output in their system configuration.
Specifications
| Features | |
|---|---|
| Country of origin | China |
| HDMI version | 2.0 |
| DisplayPort version | 1.2 |
| Product colour | Black |
| Cable length | 0.15 m |
| Connector 1 | Mini DisplayPort |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| Connector contacts plating | Copper |
| Data transfer rate | 18 Gbit/s |
| Maximum resolution | 4096 x 2160 pixels |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
| Supported video modes | 2160p |
| HDCP | Yes |
| Plug and Play | Yes |
| Certification | Meets ROHS, FCC, and CE EMI requirements |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum refresh rate | 60 Hz |
| HDCP version | 2.2 |
| Colour sampling | 4:2:2, 4:4:4, 4:2:0 |
| Certificates | |
| Certification | Meets ROHS, FCC, and CE EMI requirements |
| Compliance certificates | RoHS |
| Technical details | |
| Country of origin | China |
| Harmonized System (HS) code | 8544 4290 |
| Plastic packaging weight | 11 g |
| Compliance certificates | RoHS |
| Other features | |
| Width | 150 mm |
| Packaging composition | |
| Plastic packaging weight | 11 g |
| Paper/cardboard packaging weight | 0 g |
| Total plastic packaging weight | 0 g |
| Total paper/cardboard packaging weight | 0 g |
| Weight & dimensions | |
| Width | 150 mm |
| Weight | 25 g |
| Package width | 160 mm |
| Package depth | 15 mm |
| Package height | 240 mm |
| Package weight | 33 g |
| Packaging data | |
| Package width | 160 mm |
| Package depth | 15 mm |
| Package height | 240 mm |
| Package type | Polybag |
| Package weight | 33 g |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Package type | Polybag |
| Logistics data | |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8544 4290 |
