F12 PST FAN
Introduction
The F12 PWM PST case fans are dedicated to outperform their counterparts in terms of cooling performance and noise level.
Specifications
| Performance | |
|---|---|
| Suitable location | Computer case |
| Fan connector | 4-pin + 4-pin |
| Pulse-width modulation (PWM) support | Yes |
| Rotational speed (min) | 230 RPM |
| Rotational speed (max) | 1350 RPM |
| Noise level | 0.3 sone |
| Bearing type | Fluid Dynamic Bearing (FDB) |
| Type | Fan |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Maximum airflow | 53 cfm |
| Maximum air pressure | 1 mmH2O |
| Airflow | 90.1 m³/h |
| Number of fans | 1 fan(s) |
| Quantity per pack | 1 pc(s) |
| Design | |
| Fan connector | 4-pin + 4-pin |
| Number of fans | 1 fan(s) |
| Product colour | Black |
| Cable length | 0.4 m |
| Illumination LED | No |
| Display type | Not applicable |
| Technical details | |
| Type | Fan |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Compatible processor series | Not supported |
| Maximum airflow | 53 cfm |
| Maximum air pressure | 1 mmH2O |
| Airflow | 90.1 m³/h |
| Number of fans | 1 fan(s) |
| Cable length | 0.4 m |
| Fan connector | 4-pin + 4-pin |
| Illumination LED | No |
| Ports & interfaces | |
| Fan connector | 4-pin + 4-pin |
| Power | |
| Starting voltage | 6 V |
| Voltage | 12 V |
| Rated current | 0.24 A |
| Colour | |
| Product colour | Black |
| Weight & dimensions | |
| Package depth | 27 mm |
| Package width | 123 mm |
| Package height | 123 mm |
| Width | 120 mm |
| Package weight | 130 g |
| Depth | 25 mm |
| Height | 120 mm |
| Weight | 109 g |
| Cable length | 0.4 m |
| Packaging data | |
| Package depth | 27 mm |
| Package width | 123 mm |
| Package height | 123 mm |
| Package weight | 130 g |
| Package type | Box |
| Packaging content | |
| Screws included | Yes |
| Package type | Box |
| Other features | |
| Country of origin | China |
| Harmonized System (HS) code | 84733080 |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
