EU Product - Unmanaged Switch 8-port GbE
Introduction
The EnGenius ES108 is an 8-port Gigabit Switch, ideal for SMBs looking to enhance port density. It provides a plug-and-play experience with unmanaged ports, requiring no configuration for straightforward installation. This switch features a robust, fanless design for quiet operation and includes Energy Efficient Ethernet (IEEE 802.3az) that dynamically regulates power based on network traffic. Its non-blocking performance ensures efficient, seamless network connectivity.
Specifications
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| Networking standards | IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| 10G support | No |
| Data transmission | |
| Switching capacity | 16 Gbit/s |
| Design | |
| Wall mountable | Yes |
| Product colour | Black |
| Stackable | No |
| LED indicators | Activity, Link |
| Rack mounting | No |
| Performance | |
| Fanless | Yes |
| Stackable | No |
| Power | |
| Power supply included | No |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source | AC/DC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width | 67 mm |
| Depth | 140 mm |
| Height | 26 mm |
| Weight | 227 g |
| Packaging content | |
| Quick start guide | Yes |
| Packaging data | |
| Package width | 150 mm |
| Package depth | 85 mm |
| Package height | 65 mm |
| Package weight | 342 g |
| Quick start guide | Yes |
| Technical details | |
| Product colour | Black |
| Stackable | No |
| Rack mounting | No |
| Indication | |
| LED indicators | Activity, Link |
| Other features | |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Logistics data | |
| Master (outer) case width | 350 mm |
| Master (outer) case length | 450 mm |
| Master (outer) case height | 330 mm |
| Master (outer) case gross weight | 18 kg |
| Products per master (outer) case | 50 pc(s) |
| Master (outer) case net weight | 17.1 kg |
