EU Product - GS2024S2 Switch Layer 2 Managed mit 4 Gigabit SFP - Switch - 0.1 Gbps
Introduction
A 24-GbE, 4-SFP, Layer 2 switch with a silent, fanless cooling system.
Specifications
| Management features | |
|---|---|
| Traffic classification | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2/L3 |
| Ports & interfaces | |
| SFP module slots quantity | 4 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Console port | RJ-45 |
| Power connector | AC-in jack |
| Network | |
| Cable types supported | Cat3, Cat4, Cat5 |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| Networking standards | IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4096 |
| Link aggregation | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Broadcast storm control | Yes |
| Virtual LAN features | Voice VLAN |
| IGMP snooping | Yes |
| Optical fiber | |
| Fiber type | Multi-mode |
| Data transmission | |
| Jumbo frames | 9600 |
| Packet buffer memory | 0.5 MB |
| MAC address table | 8192 entries |
| Switching capacity | 58 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 43.152 Mpps |
| Number of VLANs | 4096 |
| Security | |
| IP-MAC-Port binding | Yes |
| Authentication | Port-based authentication |
| SSH/SSL support | Yes |
| IGMP snooping | Yes |
| Authentication type | AAA, TACACS+ |
| DHCP features | DHCP Option 82, DHCP server, DHCP snooping |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| IPv4 & IPv6 features | IPv6 Telnet |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| LED indicators | Activity, Link, Power, System |
| Rack mounting | Yes |
| Performance | |
| Memory type | DDR-SDRAM |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Packet buffer memory | 0.5 MB |
| Stackable | Yes |
| Power | |
| Power supply included | Yes |
| AC input voltage | 90 - 260 V |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| Power connector | AC-in jack |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4096 |
| Virtual LAN features | Voice VLAN |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 204 mm |
| Height | 44 mm |
| Weight | 2.45 kg |
| Packaging data | |
| Package type | Box |
| Package width | 500 mm |
| Package depth | 290 mm |
| Package height | 85 mm |
| Package weight | 3.06 kg |
| IPv4 & IPv6 features | |
| IPv4 & IPv6 features | IPv6 Telnet |
| Technical details | |
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| Rack mounting | Yes |
| Memory | |
| Packet buffer memory | 0.5 MB |
| Memory type | DDR-SDRAM |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Indication | |
| LED indicators | Activity, Link, Power, System |
| Other features | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
